SKF

SKF SIKAC 14 M Rod head with female thread 14 mm, M 14

Recommended Retail Price €152.99
75.60 tax incl.
€62.48 excl. VAT (incl. all environmental contributions)
On stock, immediately available.
each

  • Ordered before 20:00 - delivered as of 16/05/2026
  • Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL

Product description

These SKF rod ends contain a spherical plain bearing with a steel/bronze sliding contact surface combination. The bearing requires maintenance, sizes 6 and larger can be relubricated via a grease fitting in the housing and via the shank. The female thread is available with a left- (prefix SIL) or right-hand thread.

  • Suitable where lubricant starvation might occur
  • Simple and ready-to-mount
  • Easy to relubricate (sizes >= 6)
Key features according to our expert
  • Inner diameter: 14 mm
  • Connection type: Inner thread
  • Thread type: Metric
  • Seal (bearing): Without seal
  • Maintenance free: Nein
  • Connection size: M14
Specifications / All features
  • Brand: SKF
  • EAN: 7316577032546
  • Supplier number: SKF SIKAC 14 M
Inner diameter
14 mm
Connection type
Inner thread
Thread type
Metric
Seal (bearing)
Without seal
Maintenance free
Nein
Connection size
M14
Basic static load rating
20.4
Attachment feature, rod end shank
Right-hand female thread
Material, housing
Steel
Sliding contact surface combination
Steel/bronze
Housing length, total
76
Maintenance
Relubrication required
Thread designation
M 14
Outside diameter, housing eye
37
Bore diameter, bearing inner ring
14
Sealing
Without
Material, inner ring
Bearing steel
Width, bearing inner ring
19
Width, housing eye
14.5
Basic dynamic load rating
17
Centre height, housing (from end of shank)
57
