What thread specification does this rod end have?

This rod end features a left-hand male thread with size M30x2.

What is the bore diameter of the bearing?

The inner bore diameter of the spherical plain bearing is 30 mm.

Does this SKF rod end require relubrication?

No, with its steel/PTFE sintered bronze sliding contact surface, it is maintenance-free.

Is this rod end equipped with seals?

No, this standard variant is manufactured without seals.

What does the prefix SAL designate for SKF rod ends?

The prefix SAL designates a rod end with a left-hand male thread.

SKF SAL 30 C Rod head with male thread, left-hand thread 30 mm, M 30x2

Supplier number: SKF SAL 30 C | EAN 7316577003485

Recommended Retail Price €404.15

199.95 tax incl.

€165.25 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 2 products in stock.

Ordered before 20:00 - delivered tomorrow 09/10/2026
Free shipping
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Reliable motion without maintenance demands

Practical benefits

Completely maintenance-free operation: Thanks to the self-lubricating sliding surface, you eliminate the need for regular relubrication.
Precise left-hand male thread: The M30x2 left-hand external thread gives you a secure fit in your mechanical assembly.
Durable Skf rod end: Built with a 30 mm bore, it smoothly handles demanding mechanical loads in your setup.

In a nutshell

The right choise for

With the Skf sal 30 C rod end, you achieve smooth and reliable motion in your mechanical linkages without the burden of regular maintenance. Thanks to the self-lubricating steel and ptfe sintered bronze sliding surface, you eliminate the need for relubrication, making it ideal for hard-to-reach positions in machinery, cylinders, and steering systems. The M30x2 left-hand male thread allows for precise linkage length adjustments when paired with a right-hand threaded rod end. Featuring a 30 mm bore diameter, this durable rod end effortlessly handles heavy loads, angular misalignments, and oscillating movements to keep your equipment operating with maximum reliability.

Product information FAQ

€199.95

In stock - tax incl.

Key features according to our expert

Inner diameter: 30 mm
Connection type: External thread
Thread type: Metric fine - Left
Sealing (bearing): Without seals
Maintenance free: Yes
Connection size: M30 x 2

Product description

These SKF rod ends contain a spherical plain bearing with a steel/PTFE sintered bronze sliding contact surface combination. The bearing is maintenance-free. The male thread is available with a left- (prefix SAL) or right-hand thread.

Long service life
Maintenance-free
Suitable for heavy, constant direction loads
Low coefficient of friction
Simple and ready-to-mount

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 30 mm
Connection type: External thread
Thread type: Metric fine - Left
Sealing (bearing): Without seals
Maintenance free: Yes
Connection size: M30 x 2
Bore diameter, bearing inner ring: 30
Attachment feature, rod end shank: Left-hand male thread
Material, housing: Steel
Sliding contact surface combination: Steel/PTFE sintered bronze
Housing length, total: 149
Maintenance: Maintenance-free
Thread designation: M 30x2
Material, outer ring: Deep-drawing steel
Outside diameter, housing eye: 75
Sealing: Without
Basic static load rating: 104
Material, inner ring: Bearing steel
Width, bearing inner ring: 22
Width, housing eye: 20
Basic dynamic load rating: 65.5
Centre height, housing (from end of shank): 110

Brand SKF
01390071
EAN 7316577003485
Supplier number SKF SAL 30 C

Frequently asked questions about this product

Answered by specialists

What thread specification does this rod end have?: This rod end features a left-hand male thread with size M30x2.
What is the bore diameter of the bearing?: The inner bore diameter of the spherical plain bearing is 30 mm.
Does this SKF rod end require relubrication?: No, with its steel/PTFE sintered bronze sliding contact surface, it is maintenance-free.
Is this rod end equipped with seals?: No, this standard variant is manufactured without seals.
What does the prefix SAL designate for SKF rod ends?: The prefix SAL designates a rod end with a left-hand male thread.
