SKF SA 17 C Rod head with male thread 17 mm, M 16

Recommended Retail Price €167.71
82.95 tax incl.
€68.55 excl. VAT (incl. all environmental contributions)
On order: delivered from 28/05/2026
each

  • Ordered before 20:00 - delivered as of 28/05/2026
  • Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL

Product description

These SKF rod ends contain a spherical plain bearing with a steel/PTFE sintered bronze sliding contact surface combination. The bearing is maintenance-free. The male thread is available with a left- (prefix SAL) or right-hand thread.

  • Long service life
  • Maintenance-free
  • Suitable for heavy, constant direction loads
  • Low coefficient of friction
  • Simple and ready-to-mount
Key features according to our expert
  • Inner diameter: 17 mm
  • Connection type: Outer thread
  • Thread type: Metric
  • Seal (bearing): Without seal
  • Maintenance free: Yes
  • Connection size: M16
Specifications / All features
  • Brand: SKF
  • EAN: 7316577002563
  • Supplier number: SKF SA 17 C
Inner diameter
17 mm
Connection type
Outer thread
Thread type
Metric
Seal (bearing)
Without seal
Maintenance free
Yes
Connection size
M16
Bore diameter, bearing inner ring
17
Attachment feature, rod end shank
Right-hand male thread
Material, housing
Steel
Sliding contact surface combination
Steel/PTFE sintered bronze
Housing length, total
94
Maintenance
Maintenance-free
Thread designation
M 16
Material, outer ring
Deep-drawing steel
Outside diameter, housing eye
47
Sealing
Without
Basic static load rating
42.5
Material, inner ring
Bearing steel
Width, bearing inner ring
14
Width, housing eye
11.5
Basic dynamic load rating
22.4
Centre height, housing (from end of shank)
69
