SKF

SKF SI 30 ES Rod head with female thread 30 mm, M 30x2

Recommended Retail Price €296.52
146.80 tax incl.
€121.32 excl. VAT (incl. all environmental contributions)
On order: delivered from 28/05/2026
each

  • Ordered before 20:00 - delivered as of 28/05/2026
  • Free shipping
  • Delivery by DHL

Product description

These SKF rod ends contain a spherical plain bearing with a steel/steel sliding contact surface combination. The bearing requires maintenance and can be relubricated via a grease fitting in the housing and via the shaft. The female thread is available with a left- (prefix SIL) or right-hand thread. Some sizes have different fitting dimensions (SIA series).

  • Suitable for heavy static, alternating or impact loads
  • Simple and ready-to-mount
  • Easy to relubricate
Key features according to our expert
  • Inner diameter: 30 mm
  • Connection type: Inner thread
  • Thread type: Metric fine
  • Seal (bearing): Without seal
  • Maintenance free: Nein
  • Connection size: M30 x 2
Specifications / All features
  • Brand: SKF
  • EAN: 7316577002990
  • Supplier number: SKF SI 30 ES
Inner diameter
30 mm
Connection type
Inner thread
Thread type
Metric fine
Seal (bearing)
Without seal
Maintenance free
Nein
Connection size
M30 x 2
Bore diameter, bearing inner ring
30
Attachment feature, rod end shank
Right-hand female thread
Material, housing
Steel
Sliding contact surface combination
Steel/steel, standard
Housing length, total
149
Maintenance
Relubrication required
Thread designation
M 30x2
Material, outer ring
Bearing steel
Outside diameter, housing eye
75
Sealing
Without
Basic static load rating
116
Material, inner ring
Bearing steel
Width, bearing inner ring
22
Width, housing eye
20
Basic dynamic load rating
62
Centre height, housing (from end of shank)
110
