Product description:
- Cylindrical roller bearings have a high radial load carrying capacity and are capable of rotating at high speeds
- The rollers are guided by fixed track collars on one of the bearing rings
- The bearing ring with the track collars and roller set can be slid off from the other ring
- This makes mounting easier (especially if the bearing is to be mounted both on the shaft and on the bore with a fixed fit)
- A cylindrical roller bearing can withstand (limited) axial displacement
- Full complement cylindrical roller bearings: contain as many rollers as possible
- Double-row cylindrical roller bearing: consist of two rows of cylinders
Key features according to our expert
-
Inner diameter: 260 mm
-
Width: 80 mm
-
Number of rows: 2
-
Radial clearance: CN (Normal)
-
Material (cage): Not applicable
-
Material (bearing seal): Not applicable
-
Bore type: Cylindrical
-
Outer diameter: 320 mm
Specifications / All features
-
Brand:
SKF
-
01071775
-
EAN:
7316577742766
-
Supplier number:
SKF 319262 B
- Inner diameter
- 260 mm
- Width
- 80 mm
- Number of rows
- 2
- Radial clearance
- CN (Normal)
- Material (cage)
- Not applicable
- Material (bearing seal)
- Not applicable
- Bore type
- Cylindrical
- Outer diameter
- 320 mm
- Basic static load rating
- 240 kN
- Radial internal clearance
- CN
- Loose flange
- None
- Cage
- Without
- Relubrication feature
- With
- Lubricant
- Grease
- Sealing type
- O-rings
- Bearing part
- Complete bearing
- Number of flanges, inner ring
- 2
- Tolerance class
- Normal
- Coating
- Without
- Number of flanges, outer ring
- 3
- Bore diameter
- 260 mm
- Basic dynamic load rating
- 142 kN
- Outside diameter
- 320 mm
