SKF

SKF 29244 E spherical roller bearing cylindrical 220 x 300 x 48 mm

Recommended Retail Price €10,463.81
5,180.60 tax incl.
€4,281.49 excl. VAT (incl. all environmental contributions)
On order: delivered from 28/05/2026
each

  • Ordered before 20:00 - delivered as of 28/05/2026
  • Free shipping
  • Delivery by DHL

Product description

Spherical roller thrust bearings accommodate very heavy axial and considerable radial loads. They have the highest load rating of all thrust bearings, enabling compact, high power density bearing arrangements. By combining two or more spherical roller thrust bearings, it is possible to create a bearing arrangement that is either self-aligning, allowing misalignment of the shaft, or very stiff.

  • High load carrying capacity
  • Can accommodate combined loads
  • Allow misalignment or create very stiff bearing arrangements
  • Long service life and low friction
  • Separable design
Key features according to our expert
  • Inner diameter: 220 mm
  • Width: 48 mm
  • Outer diameter: 300 mm
Specifications / All features
  • Brand: SKF
  • EAN: 7316571200002
  • Supplier number: SKF 29244 E
Inner diameter
220 mm
Width
48 mm
Outer diameter
300 mm
Bore diameter
220
Cage
Sheet metal
Reference speed
1300
Basic static load rating
3000
Tolerance class
Normal
Locating feature, housing washer
None
Limiting speed
2200
Height
48
Basic dynamic load rating
690
Outside diameter
300
Bore type
Cylindrical
