What is the measuring range and graduation of this test indicator?

It features a measuring range of 1.5 mm and a graduation of 0.01 mm.

What applications is the Mitutoyo 513-426-10E suitable for?

It is designed for workpiece alignment on machine tools and checking roundness, flatness, or narrow recessed features.

How do you mount this dial test indicator to a holder or stand?

You can mount it using the dovetail grooves and the included 8 mm diameter stem.

Do you need to manually reverse the measuring direction?

No, it features an auto-reversing mechanism that switches direction automatically upon contact.

Is the dial face protected against dust and workshop fluids?

Yes, an O-ring bezel seal and scratch-resistant crystal help prevent dust, cutting fluids, and oil from entering the dial face.

MITUTOYO 513-426-10E swivelling probe horizontal model - 1.5mm, 0.01mm

Name: MITUTOYO 513-426-10E swivelling probe horizontal model - 1.5mm, 0.01mm
Brand: MITUTOYO
SKU: 02804315
Price: 172.6 EUR
Availability: PreOrder

Supplier number: MITUTOYO 513-426-10E | EAN 4946368675978

172.60 tax incl.

€142.64 excl. VAT (incl. all environmental contributions)

On order: delivered from 06/10/2026

Ordered before 20:00 - delivered as of 06/10/2026
Free shipping
Delivery by DHL

✆ Talk to a specialist

Precise alignment with the Mitutoyo test indicator

Practical benefits

Highly accurate measurements: The 0.01 mm graduation allows you to detect the smallest dimensional variations reliably.
Smooth and responsive mechanism: Built-in jeweled bearings minimize internal friction so you achieve high sensitivity on every check.
Reliable seal against contamination: The integrated O-ring protects the dial face from dust, cutting fluids, and oil penetration.

In a nutshell

The right choise for

With the Mitutoyo 513-426-10E dial test indicator, you achieve high-precision workpiece alignment on milling machines and lathes. Featuring a 0.01 mm graduation and a 1.5 mm measuring range, it allows you to detect minute surface variations, runout, and flatness errors even in narrow recessed areas. Built-in jeweled bearings minimize internal friction to deliver high sensitivity and immediate response on every contact. The auto-reversing mechanism ensures smooth bi-directional measurements without manual switching. An integrated O-ring seal and scratch-resistant crystal reliably protect the dial face against dust, cutting fluids, and oil. Mount it quickly to your setup using the dovetail grooves and the included 8 mm stem.

Product information FAQ

€172.60

tax incl.

Key features according to our expert

Min. measuring value: 1,5 mm
Max. measuring value: 1,5 mm
Scale: 0,01 mm

Product description:

Drastically enhanced durability, sensitivity and visibility.
Glare-free flat crystal face allows easy reading of graduations.
Preventing dust and oil from penetrating to the dial face. The O-ring seal on the bezel has the effect of providing smooth rotation and prevents dust and oil from penetrating through to the dial face.
Multi-layer coatings on the Crystal.
Hard and non-glare coatings on the crystal inhibit scratches, contamination and glare on the surface.
Jewelled bearings and precision gears and pinions give you smooth, accurate movement and quick response.

All Features

Min. measuring value: 1,5 mm
Max. measuring value: 1,5 mm
Scale: 0,01 mm

Brand MITUTOYO
02804315
EAN 4946368675978
Supplier number MITUTOYO 513-426-10E

Frequently asked questions about this product

Answered by specialists

What is the measuring range and graduation of this test indicator?: It features a measuring range of 1.5 mm and a graduation of 0.01 mm.
What applications is the Mitutoyo 513-426-10E suitable for?: It is designed for workpiece alignment on machine tools and checking roundness, flatness, or narrow recessed features.
How do you mount this dial test indicator to a holder or stand?: You can mount it using the dovetail grooves and the included 8 mm diameter stem.
Do you need to manually reverse the measuring direction?: No, it features an auto-reversing mechanism that switches direction automatically upon contact.
Is the dial face protected against dust and workshop fluids?: Yes, an O-ring bezel seal and scratch-resistant crystal help prevent dust, cutting fluids, and oil from entering the dial face.
