DEWALT

DEWALT DWS773-QS crosscut mitre saw 216 mm 1300 W

Recommended Retail Price €410.64
325.68 tax incl.
€269.16 excl. VAT (incl. all environmental contributions)
On order: delivered from 10/07/2026
each

Is this mitre saw right for you?

Answer a few questions and see if this mitre saw is a perfect match for you.

DeWALT Power Month at Klium - Maximum savings!

This DeWALT tool is part of the DeWALT Power Month at Klium.

What does this mean?

  • Spend €350 excl. VAT on DeWALT products and receive a free XR 18V 5.0Ah battery instantly (Klium only - automatically added to your shopping cart).
  • Offer valid from 01.07.2026 through 30.07.2026 or while stocks last. Once it's gone, it's gone.

Scope of delivery

  • DWS773 crosscut and mitre saw
  • Two workbench mounting bolts
  • Material clamp
  • Saw blade spanner
  • TCT tooth saw blade
  • Supplied in cardboard box

Product description

  • The classic design of the telescopic crosscut saw has been further improved and adapted to the requirements of today's user
  • Preset fixed mitre angles of 15°, 22.5°, 30°, 45°, 90° with quick-lock mechanism up to 50°
  • Compact design with internal guide rails for large cutting capacity and easy transport
  • 1300 Watt motor for excellent cutting performance in all materials
  • The support table and stop have been machined to meet the highest quality standards in the toughest applications
  • The new saw head lock allows blocking the traversing function in case of sawing small workpieces and also for safe transportation
  • Optimised dust extraction
  • Fixed left- and right-handed guide rails with measuring scale for better material support and management
  • New carrying handles for ease of transport
  • Please note: this is the version without XPS Shadow cutting line indicator (present on the DWS774)
Key features according to our expert
  • Power: 1300 W
  • Cut line indicator: LED shadow line
  • Saw blade diameter: 216 mm
  • Dust extraction position: Behind the saw blade
  • Max. width (workpiece): 250 mm
  • Max. height (workpiece): 60 mm
  • Cable length: 2 m
  • Adapter required for 35 mm vacuum cleaner hose: No
  • Tiltable left/right: Left only
  • Slide function: Yes
  • Bore size: 30 mm
  • Weight: 12 kg
  • Engine brake: No
  • With stand: No
Specifications / All features
Power
1300 W
Cut line indicator
LED shadow line
Saw blade diameter
216 mm
Dust extraction position
Behind the saw blade
Max. width (workpiece)
250 mm
Max. height (workpiece)
60 mm
Cable length
2 m
Adapter required for 35 mm vacuum cleaner hose
No
Tiltable left/right
Left only
Slide function
Yes
Bore size
30 mm
Weight
12 kg
Engine brake
No
With stand
No
Cutting capacity at 45°/90° (w x h)
30,0 mm
Weight
3,0 dB(A)
Power input
1300W
Length
2,1 m/s²
Sound pressure uncertainty
104,0 dB(A)
Height
48,0 º
Max. cutting capacity at 45°/45°
190x48 mm
Max. cutting capacity at 45° [rounded profile]
70,0 mm
Blade diameter
216,0 mm
Blade speed
4500,0 rpm
Sound power uncertainty
3,9 dB(A)
Max. cutting capacity at 45° [square profile]
48/48 º
Cutting capacity at 90°/90° (w x h)
177 x 62 mm
Max. cutting capacity at 45° [l-shape profile]
590,0 mm
Wheel diameter
1,5 m/s²
Sound pressure
93,0 dB(A)
Max. cutting capacity at 45° [rectangular profile]
490,0 mm
Sound power
Corded
Cutting capacity at 90°/45° (w x h)
173 x 62 mm
