BAHCO

BAHCO 98-11 socket spanner with rectangular connection 9x12 mm, 11 mm

Recommended Retail Price €41.19
24.95 tax incl.
€20.62 excl. VAT (incl. all environmental contributions)
On order: delivered from 26/05/2026
each

  • Ordered before 20:00 - delivered as of 26/05/2026
  • Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL

Product description:

  • Insert ring spanner, rectangular socket 9x12 mm, 11 mm

Features:

  • The insert is secured to the torque spanner with a spring-loaded retractable pin
  • Range varies from 9 x 12 to 27 x 36 holders, from 7 to 60 mm openings and from 25 to 3000Nm
  • For sizes with * in the torque length, the torque setting must be calculated
  • Suitable for 7465, 74W9, 74W14, 74P9, 74P14, IZO-D, TAW9, TAW14, TAW24, TAWM9, TAWM14 and TAWM24 spanners
Key features according to our expert
  • Ring spanner type: Single ring spanner
  • Type of drive profile: Twelve-point
  • Connection size: 9 x 12 mm
  • Connection profile: Outer rectangle
  • Drive profile size: 11 mm
Specifications / All features
  • Brand: BAHCO
  • EAN: 7314150367337
  • Supplier number: BAHCO 98-11
Ring spanner type
Single ring spanner
Type of drive profile
Twelve-point
Connection size
9 x 12 mm
Connection profile
Outer rectangle
Drive profile size
11 mm
Length and width of square mm
9x12 mm
Diameter inch
11 in
Weight g
40 g
Working length mm (l)
17 mm
Length of square mm
12 mm
Head width mm (d)
22 mm
Width mm (b)
20 mm
Total length mm (a)
42 mm
Max torque range nm
47 N·m
Weight kg
0.04 kg
Height mm (h)
9 mm
Length mm
42 mm
Width of square mm
9 mm
Diameter mm
11 mm
