BAHCO

BAHCO 98-1/4 socket spanner with rectangular connection 9x12 mm, 1/4"

Recommended Retail Price €33.17
19.95 tax incl.
€16.49 excl. VAT (incl. all environmental contributions)
On order: delivered from 23/05/2026
each

  • Ordered before 20:00 - delivered as of 23/05/2026
  • Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL

Product description:

  • Insert ring spanner, rectangular connection 9x12 mm, 1/4"

Features:

  • The insert is secured to the torque spanner with a spring-loaded retractable pin
  • The range Includes 9 x 12 and 14 x 18 holders and ranges from 1/4 to 1 inch openings and from 25 to 360Nm
  • Suitable for 7465, 74W9, 74W14, 74P9, 74P14, IZO-D, TAW9, TAW14, TAWM9 and TAWM14 spanners
Key features according to our expert
  • Ring spanner type: Single ring spanner
  • Type of drive profile: Twelve-point
  • Connection size: 9 x 12 mm
  • Connection profile: Outer rectangle
  • Drive profile size: 1/4"
Specifications / All features
  • Brand: BAHCO
  • EAN: 7314150367443
  • Supplier number: BAHCO 98-1/4
Ring spanner type
Single ring spanner
Type of drive profile
Twelve-point
Connection size
9 x 12 mm
Connection profile
Outer rectangle
Drive profile size
1/4"
Length and width of square mm
9x12 mm
Diameter inch
1/4 in
Weight g
43 g
Working length mm (l)
14 mm
Length of square mm
12 mm
Head width mm (d)
13 mm
Width mm (b)
20 mm
Total length mm (a)
40 mm
Max torque range nm
25 N·m
Weight kg
0.043 kg
Height mm (h)
8 mm
Length mm
40 mm
Width of square mm
9 mm
Diameter mm
1/4 in
