BAHCO

BAHCO 228-24 socket spanner with spigot connection 22 mm, 24 mm

442.80 tax incl.
€365.95 excl. VAT (incl. all environmental contributions)
On order: delivered from 23/05/2026
each

  • Ordered before 20:00 - delivered as of 23/05/2026
  • Free shipping
  • Delivery by DHL

Product description:

  • Insert ring spanner, spigot connection 22 mm, 24 mm

Features:

  • The insert is secured to the torque spanner with a spring-loaded retractable pin
  • The range varies from 16 to 22 holders, from 7 to 46 mm openings and from a maximum torque of 25 to 1200Nm
  • Suitable for 74S, 74 PS, 75S, 75 PS and 76S spanners
Key features according to our expert
  • Ring spanner type: Single ring spanner
  • Drive profile size: 24 mm
  • Type of drive profile: Twelve-point
  • Connection size: 22 mm
  • Connection profile: Cylindrical female
Specifications / All features
  • Brand: BAHCO
  • EAN: 7314150420087
  • Supplier number: BAHCO 228-24
Ring spanner type
Single ring spanner
Drive profile size
24 mm
Type of drive profile
Twelve-point
Connection size
22 mm
Connection profile
Cylindrical female
Max torque range nm
1200 N·m
Weight kg
1.000 kg
Total length mm (a)
113 mm
Head width mm (d)
65 mm
Weight g
1000 g
Diameter mm
24 mm
