BAHCO

BAHCO 148-36 socket spanner with rectangular connection 14x18 mm, 36 mm

Recommended Retail Price €91.96
56.20 tax incl.
€46.45 excl. VAT (incl. all environmental contributions)
On order: delivered from 23/05/2026
each

  • Ordered before 20:00 - delivered as of 23/05/2026
  • Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL

Product description:

  • Metric spanner with ring end and rectangular connector

Features:

  • The insert is secured to the torque spanner with a spring-loaded retractable pin
  • The range varies from 9 x 12 to 27 x 36 holders, from 7 to 60 mm openings and from 25 to 3000Nm
  • For sizes with * in the torque length, the torque setting must be calculated
  • Suitable for 7465, 74W9, 74W14, 74P9, 74P14, IZO-D, TAW9, TAW14, TAW24, TAWM9, TAWM14 and TAWM24 spanners
Key features according to our expert
  • Ring spanner type: Single ring spanner
  • Type of drive profile: Twelve-point
  • Connection size: 14 x 18 mm
  • Connection profile: Outer rectangle
  • Drive profile size: 36 mm
Specifications / All features
  • Brand: BAHCO
  • EAN: 7314150367702
  • Supplier number: BAHCO 148-36
Ring spanner type
Single ring spanner
Type of drive profile
Twelve-point
Connection size
14 x 18 mm
Connection profile
Outer rectangle
Drive profile size
36 mm
Length and width of square mm
14x18 mm
Diameter inch
36 in
Weight g
196 g
Working length mm (l)
30 mm
Length of square mm
18 mm
Head width mm (d)
53 mm
Width mm (b)
53 mm
Total length mm (a)
80 mm
Max torque range nm
360 N·m
Weight kg
0.196 kg
Height mm (h)
19 mm
Length mm
*30 mm
Width of square mm
14 mm
Diameter mm
36 mm
