Which torque wrenches are compatible with this open-ended insert?

It fits torque wrenches with a 14 x 18 mm rectangular receiver, such as Bahco 7465, 74W14, 74P14, IZO-D, TAW14, and TAWM14.

What is the wrench size of this insert?

The open-end size of this insert tool is 41 mm.

How is the insert secured to the torque wrench?

The insert is held securely in place by a spring-loaded retractable pin.

Is torque calculation required when using this insert?

Yes, due to the extended torque length offset, target torque calculation is required.

BAHCO 147-41 socket spanner with rectangular connection 14x18 mm, 41 mm

Name: BAHCO 147-41 socket spanner with rectangular connection 14x18 mm, 41 mm
Brand: BAHCO
SKU: 03052666
Price: 55.8 EUR
Availability: InStock

Supplier number: BAHCO 147-41 | EAN 7314150366859

Recommended Retail Price €91.38

55.80 tax incl.

€46.12 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 2 products in stock.

Ordered before 20:00 - delivered as of 13/10/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

✆ Talk to a specialist

Reliable torque tightening with Bahco

Practical benefits

Secure spring pin connection: The spring-loaded retractable pin ensures you lock the insert firmly onto your compatible torque wrench.
Broad size for heavy fittings: Designed with a 41 mm opening, you easily fasten large nuts and bolts with consistent engagement.
Standard rectangular receiver fit: The 14X18 mm drive allows you to fit the tool seamlessly into matching torque wrench holders.

In a nutshell

The right choise for

With the Bahco 147-41 open-ended insert, you tighten large nuts, bolts, and hydraulic fittings with exact torque control. Whenever pipes or wiring prevent you from fitting a standard socket or box wrench, this 41 mm open-end insert delivers the access you need. Designed with a standard 14X18 mm rectangular receiver drive, it mounts effortlessly onto your compatible torque wrench. The spring-loaded retractable pin ensures a firm and secure lock, giving you complete confidence and precision during heavy equipment maintenance, pipefitting, and vehicle assembly tasks.

Product information FAQ

€55.80

In stock - tax incl.

Key features according to our expert

Width across flats: 41 mm
Connection size (wrench): 14 x 18 mm
Connection type (wrench): External rectangle

Product description:

Open-ended metric spanner with rectangular connector

Features:

The insert is secured to the torque spanner with a spring-loaded retractable pin
The range varies from 9 x 12 to 27 x 36 holders, from 7 to 90 mm openings and from 9 to 3000Nm
For sizes with * in the torque length, the torque setting must be calculated
Suitable for 7465, 74W9, 74W14, 74P9, 74P14, IZO-D, TAW9, TAW14, TAW24, TAWM9, TAWM14 and TAWM24 spanners

All Features

Width across flats: 41 mm
Connection size (wrench): 14 x 18 mm
Connection type (wrench): External rectangle
Diameter inch: 41 in
Weight g: 430 g
Working length mm (l): 50 mm
Length of square mm: 18 mm
Head width mm (d): 84 mm
Width mm (b): 84 mm
Total length mm (a): 90 mm
Length and width of square mm: 14x18 mm
Height mm (h): 14 mm
Weight kg: 0.43 kg
Max torque range nm: 360 N·m
Length mm: *50 mm
Width of square mm: 14 mm
Diameter mm: 41 mm

Brand BAHCO
03052666
EAN 7314150366859
Supplier number BAHCO 147-41

Frequently asked questions about this product

Answered by specialists

Which torque wrenches are compatible with this open-ended insert?: It fits torque wrenches with a 14 x 18 mm rectangular receiver, such as Bahco 7465, 74W14, 74P14, IZO-D, TAW14, and TAWM14.
What is the wrench size of this insert?: The open-end size of this insert tool is 41 mm.
How is the insert secured to the torque wrench?: The insert is held securely in place by a spring-loaded retractable pin.
Is torque calculation required when using this insert?: Yes, due to the extended torque length offset, target torque calculation is required.
