SPIT 062770 ATP chemical female threaded anchor M8 60

Name: SPIT 062770 ATP chemical female threaded anchor M8 60
Brand: SPIT
SKU: 02507903
Price: 5.03 EUR
Availability: PreOrder

5.03 tax incl.

€4.16 excl. VAT (incl. all environmental contributions)

€5.03

On order: delivered from 21/05/2026

each

The minimum purchase order quantity for the product is 10.

Ordered before 20:00 - delivered as of 21/05/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

Strong internal threaded anchor for use with SPIT injection mortar
High-performance internal threaded anchor for heavy loads, used with SPIT mortars
Small installation depth and short edge distance
Large surface area between injection mortar and substrate results in large loads
Internal thread so that various fasteners, heads and steel types can be used
Special cap prevents contamination of the thread and allows countersunk finishing
Special length in M12 for signage in asphalt applications

Key features according to our expert

Specifications / All features

Wire dimension: 8
Min. thickness of base material: 100 mm
Health and safety: Eye protection, Gloves, Hearing protection, Helmet
Min. edge distance (mm): 40 mm
Product material: Carbon steel
Head type: Flat head
Base material colour: GREY
Min. anchor distance: 40 mm
Internal thread diameter: 8.0 mm
Anchor diameter: 8.0 mm
Anchoring depth: 60 mm
Tightening torque: 10 N-m
Minimum drilling depth: 65 mm
Drill diameter: 14.0 mm
Base material: Asphalt, Non-cracked concrete, Solid blocks, Solid brick, Stone
Maximum installation depth: 60 mm
Throughput diameter: 9 mm
Anchor length: 60 mm
Wire diameter: M8
Treatment: Galvanised
