SPIT

SPIT 057672 FIX Z XTREM breach anchor M12x220 for cracked and uncracked concrete

6.72 tax incl.
€5.55 excl. VAT (incl. all environmental contributions)
On order: delivered from 28/05/2026
each

The minimum purchase order quantity for the product is 20.

  • Ordered before 20:00 - delivered as of 28/05/2026
  • Free shipping
  • Delivery by DHL

Product description

  • Piercing anchor for cracked and non-cracked concrete and seismic applications
  • ETA-approved quality anchor for safety applications
  • No wood deformation thanks to extra-large ring according to DIN 440 / ISO 7094
  • Widely applicable XTREM anchor thanks to CE approval for use in cracked and non-cracked concrete
  • High load capacity thanks to special geometry and segment thickness
  • High allowable loads thanks to special geometry and thickness of segment
  • Large range that can be used in all seismic C1 and C2 areas
  • Geometry ensures easy placement and fast installation due to minimum number of rotations
  • Maximum flexibility in thanks to fully continuous screw act

Applications

  • Steel structures
  • Safety fences
  • Curtain wall
  • Purlin
  • Wooden panel
  • HVAC
  • Timber structures
Key features according to our expert
  • Thread dimension: M12
  • Surface treatment (bolt): Zinc plated
  • Overall length: 220 mm
Specifications / All features
  • Brand: SPIT
  • EAN: 3439510576724
  • Supplier number: SPIT 057672
Thread dimension
M12
Surface treatment (bolt)
Zinc plated
Overall length
220 mm
Drill diameter
12.0 mm
Treatment
Galvanised
Min. edge distance (mm)
70 mm
Product material
Carbon steel
Head type
Loose nut head
Min. anchor distance
70 mm
Anchor diameter
12.0 mm
Maximum trapping
125 mm
Tightening torque
60 N-m
Min. thickness of base material
140 mm
Minimum drilling depth
85 mm
Base material
Cracked concrete, Non-cracked concrete
Minimum placement depth
50.0 mm
Maximum installation depth
70 mm
Throughput diameter
14 mm
Anchor length
220 mm
Wire diameter
M12
Key size
19.0 mm
Anchor screw material
Steel
