SPIT 057600 insulation plug with plastic dowel for EPS insulation (Ø60) 10x30

Name: SPIT 057600 insulation plug with plastic dowel for EPS insulation (Ø60) 10x30
Brand: SPIT
SKU: 02345307
Price: 0.19 EUR
Availability: PreOrder

Supplier number: SPIT 057600 | EAN 3439510576007

0.19 tax incl.

€0.16 excl. VAT (incl. all environmental contributions)

On order: delivered from 14/10/2026

The minimum purchase order quantity for the product is 200.

Ordered before 20:00 - delivered as of 14/10/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Product information

€0.19

tax incl.

Key features according to our expert

Head diameter: 60 mm
With screw: Yes
Max. insulation thickness: 30 mm
Wall plug type: Insulation plug
Application: Brick; Aerated concrete
With collar: Yes
Drilling diameter: 10 mm
Diameter (wall plug): - mm
Material (wall plug): PP - Polypropylene
Length (Wall plug): 60 mm

Product description

Insulation plug with plastic nail for fixing expanded polyester (EPS) and mineral insulation boards in ETICS system
Expansion insulation plug with striking pin perfectly suited for EPS insulation
Suitable for all base materials for ETICS applications
High pull-out values: 150 kg in concrete for optimum anchor consumption per m2
Secure ETICS fastening
Optimal thermal transfer < 0.002 W/K
Low depth: 25 mm
Expansions for quick and easy fixing
Pre-assembled anchor for faster installation
Special panel surface for optimal adhesion.
Suitable for thick insulation boards.
ETICS use categories: A - B - C - D - E.

Applications

Window hooks
Suspended ceilings
Cladding
Duct & conduit systems

Documents

⤓ Declaration of Conformity PDF

All Features

Head diameter: 60 mm
With screw: Yes
Max. insulation thickness: 30 mm
Wall plug type: Insulation plug
Application: Brick; Aerated concrete
With collar: Yes
Drilling diameter: 10 mm
Diameter (wall plug): - mm
Material (wall plug): PP - Polypropylene
Length (wall plug): 60 mm
Minimum drilling depth: 50 mm
Product material: Polypropylene
Thermal properties: 0,001
Head type: Ring head
Base material colour: PURPLE
Min. anchor distance: 100 mm
Anchor diameter: 10.0 mm
Maximum trapping: 30 mm
Anchoring depth: 30 mm
Min. thickness of base material: 100 mm
Minimum clamping thickness: 10 mm
Drill diameter: 10.0 mm
Minimum placement depth: 30.0 mm
Base material: Hollow blocks, Hollow bricks, Non-cracked concrete, Solid blocks, Solid brick
Maximum installation depth: 30 mm
Anchor length: 60 mm
Min. edge distance (mm): 100 mm
