Which shaft diameter is this bearing unit suitable for?

This flanged bearing unit is designed for shafts with a 60 mm diameter and cylindrical bore.

How is the shaft secured into the bearing?

The shaft is firmly locked using set screws located on the extended inner ring.

What material is the housing made of?

The square housing is made of cast iron and the insert bearing is made of steel.

Which standard does this flanged bearing unit follow?

This unit complies with the Japanese Industrial Standards (JIS) for square flanged housings.

Is this unit suitable for high-temperature environments?

No, this model is not designed for high-temperature applications.

SKF UCF 212/H ball bearing unit with square flange and locking with set screw, cast iron bearing housing, JIS

Supplier number: SKF UCF 212/H | EAN 7316579751629

Recommended Retail Price €203.70

100.80 tax incl.

€83.31 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 1 products in stock.

Ordered before 20:00 - delivered as of 12/10/2026
Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

✆ Talk to a specialist

Dependable shaft support with Skf

Practical benefits

Simple and secure mounting: You bolt the square cast iron housing firmly to machine walls or frames using four fasteners.
Reliable set screw locking: The integrated set screw system firmly grips your 60 mm shaft during constant or alternating rotation.
Robust cast iron construction: The durable cast iron housing reliably supports the steel insert bearing under heavy mechanical loads.

In a nutshell

The right choise for

With the Skf ucf 212/H flanged bearing unit, you mount rotating 60 mm shafts quickly and securely onto machine frames or conveyor systems. Built to jis standards, this ready-to-mount unit pairs a robust cast iron housing with a durable steel insert bearing. The square four-bolt flange attaches directly to flat surfaces perpendicular to the shaft axis. Integrated set screws on the extended inner ring lock the shaft firmly against axial displacement during constant or alternating rotation. In addition, the spherical outer design accommodates initial static misalignment, ensuring smooth operation and dependable performance under heavy mechanical loads.

Product information FAQ

€100.80

In stock - tax incl.

Key features according to our expert

Shaft diameter: 60 mm
Material (bearing housing): Cast iron
Material (bearing): Steel
High temperature: No
Bore type: Cylindrical
Shape (bearing housing): Square

Product description

These square flanged ball bearing units are compliant with Japanese Industrial Standards (JIS). They consist of an insert bearing, with an extended inner ring and set screw locking, and are suitable for applications where the direction of rotation is constant or alternating. The bearing is mounted in a cast iron housing, which can be bolted to a machine wall or frame. Ball bearing units can accommodate moderate initial misalignment, but normally do not permit axial displacement.

Resist high levels of contamination
Designed for high temperatures and speeds
Accommodate relatively heavy loads
Cost-effective

All Features

Shaft diameter: 60 mm
Material (bearing housing): Cast iron
Material (bearing): Steel
High temperature: No
Bore type: Cylindrical
Shape (bearing housing): Square
Material, bearing: Bearing steel
Number of bolt holes for fasteners: 4
Lubricant: Grease
Rubber seating ring: Without
Sealing type: Contact, standard
Sealing, bearing: Seal and flinger on both sides
Housing type: Flanged
Flanged housing type: Square
Bearing width, total: 65.1
Application: For material handling applications
Note: Limiting speed with shaft tolerance h6
Hexagonal key size for set screw: 5
Grease fitting: With
Material, housing: Cast iron
Basic static load rating: 36
Attachment bolt diameter: 16
Retaining feature, inner ring: Set screws
Basic dynamic load rating: 52.7
Coating: Without
Housing overall width: 47.5
Centre distance between bolt holes: 143
Relubrication hole: With
Fastening bolt hole type: Plain
Limiting speed: 2700
Width, total: 68.7
Sealing, unit: Optional end cover
Set screw: M10x1

Brand SKF
03031935
EAN 7316579751629
Supplier number SKF UCF 212/H

Frequently asked questions about this product

Answered by specialists

Which shaft diameter is this bearing unit suitable for?: This flanged bearing unit is designed for shafts with a 60 mm diameter and cylindrical bore.
How is the shaft secured into the bearing?: The shaft is firmly locked using set screws located on the extended inner ring.
What material is the housing made of?: The square housing is made of cast iron and the insert bearing is made of steel.
Which standard does this flanged bearing unit follow?: This unit complies with the Japanese Industrial Standards (JIS) for square flanged housings.
Is this unit suitable for high-temperature environments?: No, this model is not designed for high-temperature applications.
