skf_u320
SKF

SKF U 320 Spherical housing ring for ball bearing

Recommended Retail Price €454.17
224.80 tax incl.
€185.79 excl. VAT (incl. all environmental contributions)
On order: delivered from 26/05/2026
each

  • Ordered before 20:00 - delivered as of 26/05/2026
  • Free shipping
  • Delivery by DHL

Product description

  • Sphered seat washers are used together with thrust ball bearings with sphered housing washers when the bearing is fitted into a machine component manufactured with a flat surface. The seat washers are supplied as separate components. Depending on bearing series, they have the basic designation U 2, U 3 or U 4 followed by a two-digit number, which identifies the size, e.g. sphered seat washer U 320 for bearing 53320.

Avantages

  • Enable the bearings to accommodate initial misalignment
  • Can be used with single or double direction bearings
  • Enable full interchangeability of seat washers
Key features according to our expert
  • Inner diameter: 135 mm
  • Outer diameter: 175 mm
  • Thickness: 18 mm
Specifications / All features
  • Brand: SKF
  • EAN: 7316570611700
  • Supplier number: SKF U 320
Inner diameter
135 mm
Outer diameter
175 mm
Thickness
18 mm
Outside diameter
175 mm
Material
Bearing steel
Coating
Without
Bore diameter
135 mm
