skf_u309

SKF U 309 Spherical housing ring for ball bearing

Supplier number: SKF U 309 | EAN 7316577009388
Recommended Retail Price €148.50
73.40 tax incl.
€60.66 excl. VAT (incl. all environmental contributions)
On stock - immediately available | we have 6 products in stock.

  • Ordered before 20:00 - delivered tomorrow 24/11/2026
  • Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 75 euros
  • Delivery by DHL

Precise alignment for thrust ball bearings

Practical benefits
  • Reliable correction of mounting misalignment: The spherical seating face compensates for angular errors between the shaft and housing, keeping your bearings operating smoothly.
  • Heavy duty sphered seat washer: Designed with a 65 mm bore and 90 mm outside diameter, this component sits flush against flat housing surfaces.
  • Balanced distribution of axial loads: A solid 10 mm thickness distributes high thrust forces across the housing to prevent localized wear during heavy machinery use.

In a nutshell

The right choise for

The Skf u 309 sphered seat washer establishes dependable alignment when mounting a thrust ball bearing against a flat housing surface. Its sphered seating surface accommodates initial angular errors between the shaft and housing, eliminating edge stresses and keeping your machinery running smoothly.

Engineered for use with the Skf 53309 thrust ball bearing, this component features a 65 mm bore diameter, a 90 mm outside diameter, and a solid 10 mm thickness. These proportions distribute high axial loads evenly across the housing structure. You effectively extend the operational life of your rotating assemblies during demanding industrial operation.



€73.40
In stock - tax incl.

Product information

Key features according to our expert

  • Inner diameter: 65 mm
  • Outer diameter: 90 mm
  • Thickness: 10 mm

Product description

Sphered seat washers are used together with thrust ball bearings with sphered housing washers when the bearing is fitted into a machine component manufactured with a flat surface. The seat washers are supplied as separate components. Depending on bearing series, they have the basic designation U 2, U 3 or U 4 followed by a two-digit number, which identifies the size, e.g. sphered seat washer U 320 for bearing 53320.

  • Enable the bearings to accommodate initial misalignment
  • Can be used with single or double direction bearings
  • Enable full interchangeability of seat washers

Documents

All Features

Inner diameter
65 mm
Outer diameter
90 mm
Thickness
10 mm
Outside diameter
90
Height
10
Material
Bearing steel
Coating
Without
Bore diameter
65
  • Brand SKF
  • EAN 7316577009388
  • Supplier number SKF U 309

Frequently asked questions about this product

Answered by specialists
What is the purpose of the Skf u 309 sphered seat washer?
It accommodates initial angular misalignment when mounting a thrust ball bearing against a flat housing surface.
Which bearing is this washer designed for?
This seat washer is designed for use with the Skf 53309 thrust ball bearing.
What are the dimensions of the Skf u 309?
It features a 65 mm bore diameter, a 90 mm outside diameter, and a thickness of 10 mm.
Is the thrust ball bearing included with the washer?
No, seat washers are supplied as separate components and must be purchased individually.
Can this seat washer support radial loads?
No, this component is intended purely for axial arrangements with thrust ball bearings.
