Supplier number:
SKF SYFWK 40 LTA
|
EAN
7316574958948
Product information
Key features according to our expert
- Shaft diameter: 40 mm
- Bore type: Cylindrical
- Material (bearing housing): Composite
- Material (bearing): Steel
All Features
- Shaft diameter
- 40 mm
- Bore type
- Cylindrical
- Material (bearing housing)
- Composite
- Material (bearing)
- Steel
- Material, bearing
- Bearing steel
- Sealing, bearing
- Seal and flinger on both sides
- Sealing type
- Contact, multiple
- Centre distance between bolt holes
- 88.9 mm
- Centre height (pillow block)
- 49.2 mm
- Lubricant
- Grease
- Number of bolt holes for fasteners
- 2
- Basic static load rating
- 19 kN
- Material, housing
- Composite for the SKF Food Line
- Bearing width, total
- 49.2 mm
- Retaining feature, inner ring
- Set screws
- Rubber seating ring
- Without
- Note
- Limiting speed with shaft tolerance h6
- Grease fitting
- Without
- Sealing, unit
- Optional end cover
- Limiting speed
- 2,800 r/min
- Fastening bolt hole type
- Threaded
- Relubrication hole
- Without
- Housing overall width
- 48 mm
- Basic dynamic load rating
- 30.7 kN
- Coating
- Zinc-coated bearing
- Housing type
- Pillow block
- Brand SKF
- EAN 7316574958948
- Supplier number SKF SYFWK 40 LTA
