SKF SILKB 20 F rod head with female thread, left-hand thread 20 mm, M 20x1.5

Supplier number: SKF SILKB 20 F | EAN 7316577001962

Recommended Retail Price €253.42

125.40 tax incl.

€103.64 excl. VAT (incl. all environmental contributions)

On order: delivered from 20/10/2026

Ordered before 20:00 - delivered as of 20/10/2026
Free shipping
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Product information

€125.40

tax incl.

Key features according to our expert

Inner diameter: 20 mm
Connection type: Internal thread
Thread type: Metric fine - Left
Sealing (bearing): Without seals
Maintenance free: Yes
Connection size: M20 x 1,5

Product description

These SKF rod ends have an injection moulded sliding layer of PTFE FRP between the housing and the inner ring. This sliding contact surface combination is maintenance-free. The male thread is available with a left- (prefix SAL) or right-hand thread.

Long service life
Maintenance-free
Relatively insensitive to contaminants
Low coefficient of friction
Simple and ready-to-mount

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 20 mm
Connection type: Internal thread
Thread type: Metric fine - Left
Sealing (bearing): Without seals
Maintenance free: Yes
Connection size: M20 x 1,5
Basic static load rating: 50
Attachment feature, rod end shank: Left-hand female thread
Material, housing: Steel
Sliding contact surface combination: Steel/PTFE FRP
Housing length, total: 105
Maintenance: Maintenance-free
Thread designation: M 20x1.5
Outside diameter, housing eye: 51
Bore diameter, bearing inner ring: 20
Sealing: Without
Material, inner ring: Bearing steel
Width, bearing inner ring: 25
Width, housing eye: 18.5
Basic dynamic load rating: 31
Centre height, housing (from end of shank): 77

Brand SKF
01390083
EAN 7316577001962
Supplier number SKF SILKB 20 F
