SKF SILKAC 8 M Rod head with female thread, left-hand thread 8 mm, M 8

Supplier number: SKF SILKAC 8 M | EAN 7316577043481

Recommended Retail Price €79.41

39.20 tax incl.

€32.40 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 3 products in stock.

Ordered before 20:00 - delivered tomorrow 30/09/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Precise linkage motion with Skf

Practical benefits

Quick and secure fitting: With the internal M8 left-hand thread, you mount this rod end accurately into your mechanical linkage.
Smooth load-bearing movement: The steel-on-bronze sliding surface ensures optimal movement while handling dynamic mechanical stresses reliably.
Easy relubrication for longevity: You can easily regrease the spherical plain bearing through the lubrication fitting to extend its service life.

In a nutshell

The right choise for

With the Skf silkac 8 M rod end, you transfer mechanical forces reliably across linkages, control rods, and cylinder connections. The internal M8 left-hand thread and 8 mm bore allow for accurate mounting and fine adjustments when paired with right-hand threaded components. Featuring an open design with a steel-on-bronze sliding contact surface combination, it smoothly accommodates dynamic loads and oscillating pivoting movements. The integrated grease fitting ensures quick and convenient relubrication during regular maintenance, helping you reduce wear and keep your machinery running smoothly.

Product information FAQ

€39.20

In stock - tax incl.

Key features according to our expert

Inner diameter: 8 mm
Connection type: Internal thread
Thread type: Metric - Left
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M8

Product description

These SKF rod ends contain a spherical plain bearing with a steel/bronze sliding contact surface combination. The bearing requires maintenance, sizes 6 and larger can be relubricated via a grease fitting in the housing and via the shank. The female thread is available with a left- (prefix SIL) or right-hand thread.

Suitable where lubricant starvation might occur
Simple and ready-to-mount
Easy to relubricate (sizes >= 6)

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 8 mm
Connection type: Internal thread
Thread type: Metric - Left
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M8
Basic static load rating: 9.15
Attachment feature, rod end shank: Left-hand female thread
Material, housing: Steel
Sliding contact surface combination: Steel/bronze
Housing length, total: 49
Maintenance: Relubrication required
Thread designation: M 8
Outside diameter, housing eye: 25
Bore diameter, bearing inner ring: 8
Sealing: Without
Material, inner ring: Bearing steel
Width, bearing inner ring: 12
Width, housing eye: 9.5
Basic dynamic load rating: 7.2
Centre height, housing (from end of shank): 36

Brand SKF
01390462
EAN 7316577043481
Supplier number SKF SILKAC 8 M

Frequently asked questions about this product

Answered by specialists

What thread type does this SKF rod end have?: It features an M8 metric left-hand female thread.
What is the bore diameter of the bearing?: The bearing bore diameter is 8 mm.
Is the SKF SILKAC 8 M maintenance-free?: No, this rod end requires regular maintenance and relubrication.
What sliding contact surface combination is used?: It uses a steel/bronze sliding contact surface combination.
Does this rod end have integrated seals?: No, this model is designed as an open unit without seals.
