SKF SIKAC 8 M Rod head with female thread 8 mm, M 8

Supplier number: SKF SIKAC 8 M | EAN 7316577027092

Recommended Retail Price €75.56

37.20 tax incl.

€30.74 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Ordered before 20:00 - delivered tomorrow 30/09/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Reliable linkage control with Skf

Practical benefits

Direct and simple mounting: The M8 female thread lets you secure the rod end quickly onto threaded shafts.
Smooth angular alignment: With an 8 mm bore, it accommodates tilting and oscillating movements under heavy mechanical loads.
Easy relubrication access: You can easily regrease the bearing surface via the housing fitting for extended component life.

In a nutshell

The right choise for

With the Skf sikac 8 M rod end, you ensure smooth and reliable mechanical force transmission across articulated machinery and linkages. The metric M8 female thread lets you mount and adjust connections directly on threaded shafts or cylinders. Its spherical plain bearing with an 8 MM bore accommodates angular misalignment under dynamic loads, preventing binding and component wear. Built without seals and featuring a steel-on-bronze sliding contact surface, this rod end requires periodic maintenance and can be easily regreased via its housing fitting to keep your mechanical systems running smoothly.

Product information FAQ

€37.20

In stock - tax incl.

Key features according to our expert

Inner diameter: 8 mm
Connection type: Internal thread
Thread type: Metric
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M8

Product description

These SKF rod ends contain a spherical plain bearing with a steel/bronze sliding contact surface combination. The bearing requires maintenance, sizes 6 and larger can be relubricated via a grease fitting in the housing and via the shank. The female thread is available with a left- (prefix SIL) or right-hand thread.

Suitable where lubricant starvation might occur
Simple and ready-to-mount
Easy to relubricate (sizes >= 6)

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 8 mm
Connection type: Internal thread
Thread type: Metric
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M8
Basic static load rating: 9.15
Attachment feature, rod end shank: Right-hand female thread
Material, housing: Steel
Sliding contact surface combination: Steel/bronze
Housing length, total: 49
Maintenance: Relubrication required
Thread designation: M 8
Outside diameter, housing eye: 25
Bore diameter, bearing inner ring: 8
Sealing: Without
Material, inner ring: Bearing steel
Width, bearing inner ring: 12
Width, housing eye: 9.5
Basic dynamic load rating: 7.2
Centre height, housing (from end of shank): 36

Brand SKF
01390269
EAN 7316577027092
Supplier number SKF SIKAC 8 M

Frequently asked questions about this product

Answered by specialists

What thread connection does this rod end have?: This rod end features a standard metric M8 female right-hand thread.
What is the bore diameter of the bearing?: The inner bore diameter of the spherical plain bearing is 8 mm.
Is this SKF rod end maintenance-free?: No, this model requires maintenance and periodic relubrication.
What sliding contact surface combination does it use?: It features a steel-on-bronze sliding contact surface combination.
Does this rod end include seals?: No, this model is designed without integrated seals.
