SKF SIKAC 6 M Rod head with female thread 6 mm, M 6

Supplier number: SKF SIKAC 6 M | EAN 7316577001870

Recommended Retail Price €72.45

35.80 tax incl.

€29.59 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Ordered before 20:00 - delivered tomorrow 29/09/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Dependable motion control with Skf

Practical benefits

Fast and simple installation: With its M6 female thread and 6 mm bore, you easily mount this rod end onto matching components.
Convenient relubrication for longevity: You can relubricate the sliding contact surface via the grease fitting to maintain smooth operation under continuous use.
Strong dynamic load support: The durable steel construction allows you to handle oscillating movements and mechanical loads with consistent reliability.

In a nutshell

The right choise for

With the Skf sikac 6 M rod end, you ensure reliable, smooth motion control in mechanical linkages and cylinder assemblies. Featuring a right-hand metric M6 female thread and a 6 mm bore, it mounts quickly and directly onto matching rods. The integrated spherical plain bearing accommodates angular misalignment effortlessly while handling dynamic tensile and compressive loads. Thanks to the durable steel/bronze sliding contact surface combination and the built-in grease fitting, you can easily relubricate the bearing to maintain optimal performance and prevent wear under continuous operation.

Product information FAQ

€35.80

In stock - tax incl.

Key features according to our expert

Inner diameter: 6 mm
Connection type: Internal thread
Thread type: Metric
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M6

Product description

These SKF rod ends contain a spherical plain bearing with a steel/bronze sliding contact surface combination. The bearing requires maintenance, sizes 6 and larger can be relubricated via a grease fitting in the housing and via the shank. The female thread is available with a left- (prefix SIL) or right-hand thread.

Suitable where lubricant starvation might occur
Simple and ready-to-mount
Easy to relubricate (sizes >= 6)

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 6 mm
Connection type: Internal thread
Thread type: Metric
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M6
Basic static load rating: 5.4
Attachment feature, rod end shank: Right-hand female thread
Material, housing: Steel
Sliding contact surface combination: Steel/bronze
Housing length, total: 41
Maintenance: Relubrication required
Thread designation: M 6
Outside diameter, housing eye: 21
Bore diameter, bearing inner ring: 6
Sealing: Without
Material, inner ring: Bearing steel
Width, bearing inner ring: 9
Width, housing eye: 7.5
Basic dynamic load rating: 4.3
Centre height, housing (from end of shank): 30

Brand SKF
01390455
EAN 7316577001870
Supplier number SKF SIKAC 6 M

Frequently asked questions about this product

Answered by specialists

What thread connection does this rod end feature?: This rod end has a metric right-hand female thread of size M6.
Is the SKF SIKAC 6 M maintenance-free?: No, this rod end requires maintenance and can be relubricated via a grease fitting.
What is the bore diameter of the bearing?: The bore diameter of the inner ring is exactly 6 mm.
What sliding contact surface combination is used?: This spherical plain bearing features a steel/bronze sliding contact combination.
Does this rod end have seals?: No, the SKF SIKAC 6 M is designed without integrated seals.
