SKF SI 35 ES-2RS Rod head with female thread 35 mm, M 36x3

Recommended Retail Price €484.16
239.60 tax incl.
€198.02 excl. VAT (incl. all environmental contributions)
On order: delivered from 28/05/2026
each

  • Ordered before 20:00 - delivered as of 28/05/2026
  • Free shipping
  • Delivery by DHL

Product description

These SKF rod ends contain a spherical plain bearing with a steel/steel sliding contact surface combination and a double-lip contact seal on both sides. The bearing requires maintenance and can be relubricated via a grease fitting in the housing and via the shaft. The female thread is available with a left- (prefix SIL) or right-hand thread. Some sizes have different fitting dimensions (SIA series).

  • Long service life
  • Minimal maintenance
  • Easy to relubricate
  • Suitable for heavy static, alternating or impact loads
  • Simple and ready-to-mount
Key features according to our expert
  • Inner diameter: 35 mm
  • Connection type: Inner thread
  • Thread type: Metric fine
  • Seal (bearing): Double-sided sealed
  • Maintenance free: Nein
  • Connection size: M36 x 3
Specifications / All features
  • Brand: SKF
  • EAN: 7316570583403
  • Supplier number: SKF SI 35 ES-2RS
Inner diameter
35 mm
Connection type
Inner thread
Thread type
Metric fine
Seal (bearing)
Double-sided sealed
Maintenance free
Nein
Connection size
M36 x 3
Bore diameter, bearing inner ring
35
Attachment feature, rod end shank
Right-hand female thread
Material, housing
Steel
Sliding contact surface combination
Steel/steel, standard
Housing length, total
174
Maintenance
Relubrication required
Thread designation
M 36x3
Material, outer ring
Bearing steel
Sealing type
Double-lip
Outside diameter, housing eye
84
Width, bearing inner ring
25
Basic static load rating
134
Material, inner ring
Bearing steel
Sealing
Seal on both sides
Width, housing eye
22
Basic dynamic load rating
80
Centre height, housing (from end of shank)
130
