SKF SI 25 ES Rod head with female thread 25 mm, M 24x2

Supplier number: SKF SI 25 ES | EAN 7316577002969

Recommended Retail Price €212.14

104.95 tax incl.

€86.74 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Ordered before 20:00 - delivered tomorrow 30/09/2026
Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Dependable articulation with Skf rod end

Practical benefits

Smooth heavy load handling: You accommodate angular misalignments and heavy alternating forces reliably with the rugged steel-on-steel spherical plain bearing.
Secure metric connection: You install linkages quickly and accurately using the M24x2 female thread paired with the 25 mm bore.
Easy periodic relubrication: You maintain operational reliability and extend component life by regreasing the contact surfaces via the lubrication fitting.

In a nutshell

The right choise for

With the Skf si 25 es rod end, you establish a strong and dependable pivot connection in industrial machinery, hydraulic cylinders, and mechanical linkages. Featuring a 25 mm bore and an M24x2 metric female thread, it smoothly accommodates angular misalignment and oscillating movements while transferring heavy dynamic tensile and compressive loads. The rugged steel-on-steel contact surface can be relubricated easily via the built-in grease fitting, extending component service life and keeping your equipment running with optimal precision.

Product information FAQ

€104.95

In stock - tax incl.

Key features according to our expert

Inner diameter: 25 mm
Connection type: Internal thread
Thread type: Metric fine
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M24 x 2

Product description

These SKF rod ends contain a spherical plain bearing with a steel/steel sliding contact surface combination. The bearing requires maintenance and can be relubricated via a grease fitting in the housing and via the shaft. The female thread is available with a left- (prefix SIL) or right-hand thread. Some sizes have different fitting dimensions (SIA series).

Suitable for heavy static, alternating or impact loads
Simple and ready-to-mount
Easy to relubricate

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 25 mm
Connection type: Internal thread
Thread type: Metric fine
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M24 x 2
Bore diameter, bearing inner ring: 25
Attachment feature, rod end shank: Right-hand female thread
Material, housing: Steel
Sliding contact surface combination: Steel/steel, standard
Housing length, total: 128
Maintenance: Relubrication required
Thread designation: M 24x2
Material, outer ring: Bearing steel
Outside diameter, housing eye: 65
Sealing: Without
Basic static load rating: 90
Material, inner ring: Bearing steel
Width, bearing inner ring: 20
Width, housing eye: 18
Basic dynamic load rating: 48
Centre height, housing (from end of shank): 94

Brand SKF
01390256
EAN 7316577002969
Supplier number SKF SI 25 ES

Frequently asked questions about this product

Answered by specialists

What thread type does this SKF rod end have?: This rod end has an M24 x 2 right-hand metric fine female thread.
What is the bore diameter of the bearing?: The bore diameter (inner diameter) of this rod end is 25 mm.
Is the SKF SI 25 ES maintenance-free?: No, this steel/steel model requires regular maintenance and relubrication via the grease fitting.
Does this model come with a seal?: No, this rod end is designed without a seal.
