SKF SA 25 C Rod head with male thread 25 mm, M 24x2

SKF
Supplier number: SKF SA 25 C | EAN 7316577002617
Recommended Retail Price €231.88
114.60 tax incl.
€94.71 excl. VAT (incl. all environmental contributions)
On order: delivered from 19/10/2026

  • Ordered before 20:00 - delivered as of 19/10/2026
  • Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL
↓ Documents (1) ✆ Talk to a specialist


Product information
€114.60
tax incl.

Product information

Key features according to our expert

  • Inner diameter: 25 mm
  • Connection type: External thread
  • Thread type: Metric fine
  • Sealing (bearing): Without seals
  • Maintenance free: Yes
  • Connection size: M24 x 2

Product description

These SKF rod ends contain a spherical plain bearing with a steel/PTFE sintered bronze sliding contact surface combination. The bearing is maintenance-free. The male thread is available with a left- (prefix SAL) or right-hand thread.

  • Long service life
  • Maintenance-free
  • Suitable for heavy, constant direction loads
  • Low coefficient of friction
  • Simple and ready-to-mount

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter
25 mm
Connection type
External thread
Thread type
Metric fine
Sealing (bearing)
Without seals
Maintenance free
Yes
Connection size
M24 x 2
Bore diameter, bearing inner ring
25
Attachment feature, rod end shank
Right-hand male thread
Material, housing
Steel
Sliding contact surface combination
Steel/PTFE sintered bronze
Housing length, total
128
Maintenance
Maintenance-free
Thread designation
M 24x2
Material, outer ring
Deep-drawing steel
Outside diameter, housing eye
65
Sealing
Without
Basic static load rating
78
Material, inner ring
Bearing steel
Width, bearing inner ring
20
Width, housing eye
18
Basic dynamic load rating
51
Centre height, housing (from end of shank)
94
  • Brand SKF
  • EAN 7316577002617
  • Supplier number SKF SA 25 C
