SKF PFD 52 steel sheet bearing housing with triangular flange for insert bearings 52 x 18 mm

Supplier number: SKF PFD 52 | EAN 7316571101286

8.03 tax incl.

€6.64 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 6 products in stock.

set

Ordered before 20:00 - delivered tomorrow 30/09/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Reliable mounting with the Skf PFD 52 housing

Practical benefits

Quick and simple assembly: The two-part pressed sheet steel design allows you to fit compatible insert bearings easily onto your machinery.
Dependable corrosion protection layer: The zinc-coated finish protects the housing against moisture and rust formation across light-duty applications.
Space-saving triangular flange design: Three fastener holes ensure balanced load distribution and secure attachment even in confined installation areas.

In a nutshell

The right choise for

With the Skf pfd 52 housing, you can mount compatible Y-insert bearings quickly and reliably onto flat machine frames and walls. This two-part pressed sheet steel housing is designed for light to medium-duty applications, such as conveyor systems, packaging equipment, and agricultural machinery. Thanks to the compact triangular flange with three bolt holes, you achieve balanced load distribution while saving valuable space and weight compared to heavy cast iron units. The zinc-coated finish effectively protects the steel against moisture and rust. Simply clamp your compatible 52 mm outer diameter insert bearing between the two housing halves and fasten securely for a stable setup.

Product information FAQ

€8.03

In stock - tax incl.

Key features according to our expert

Seat diameter: 52 mm
Shape (bearing housing): Triangle
Material (bearing housing): Sheet steel

Product description

Triangular flanged pressed steel housings for insert bearings are lightweight and made from cold-rolled steel, and are zinc-coated for corrosion protection. The housings are cost-effective and designed for simple applications with light loads. The two-part housing, which has no provision for relubrication, can be ordered separately from the insert bearing, making a large number of combinations possible.

Lightweight
Cost-effective
Flexible bearing and housing combinations
Simple to mount
Protection against corrosion

Documents

⤓ Technical data sheet PDF

All Features

Seat diameter: 52 mm
Shape (bearing housing): Triangle
Material (bearing housing): Sheet steel
Grease fitting: Without
Spherical seating diameter: 52
Housing type: Flanged
Flanged housing type: Triangular
Number of bolt holes for fasteners: 3
Pitch diameter of bolt holes of round and triangle flange type housing: 76.2
Relubrication hole: Without
Fastening bolt hole type: Plain
Coating: Zinc-coated
Material, housing: Pressed steel

Brand SKF
01190646
EAN 7316571101286
Supplier number SKF PFD 52

Frequently asked questions about this product

Answered by specialists

Which bearings are compatible with this housing?: It is designed for SKF insert bearings with an outer diameter of 52 mm.
Is the insert bearing included with this housing?: No, this product contains only the two pressed steel housing halves.
How is this housing mounted?: Clamp the insert bearing between the two pressed steel halves and secure the assembly with three bolts.
Can this housing be relubricated?: No, this pressed steel housing has no lubrication hole or grease fitting.
What applications is the PFD 52 suited for?: It is designed for simple, lightweight applications with moderate loads.
