SKF LAPA 45 knee coupling 45° male G 1/4 to female G 1/4 (for LAGD, TLSD and TLMR)

Supplier number: SKF LAPA 45 | EAN 7316570466867

Recommended Retail Price €17.05

15.80 tax incl.

€13.06 excl. VAT (incl. all environmental contributions)

On order: delivered from 16/10/2026

The minimum purchase order quantity for the product is 10.

Ordered before 20:00 - delivered as of 16/10/2026
Free shipping
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Product information

€15.80

tax incl.

Key features according to our expert

Connection size 1: 1/4"
Dash size (connection 2): Not applicable
Application area: Industry
Posistionable: No
Version (coupling): 45°
Connection type 1: External thread
Figure number: Not applicable
Series connection 2 (DIN2353): Not applicable
Tube diameter 2: Not applicable
Thread type (connection 2): BSPP
Connection type 2: Internal thread
Connection size 2: 1/4"
Dash size (connection 1): Not applicable
Series connection 1 (DIN 2353): Not applicable
Tube diameter 1: Not applicable
Thread type (connection 1): BSPP

Product description

The SKF LAPA 45 accessory is an angle connection 45 degrees with threads male G 1/4 to female G 1/4 suitable for LAGD, TLSD and TLMR single point automatic lubricators.

Documents

⤓ Technical data sheet PDF

All Features

Connection size 1: 1/4"
Dash size (connection 2): Not applicable
Application area: Industry
Posistionable: No
Version (coupling): 45°
Connection type 1: External thread
Figure number: Not applicable
Series connection 2 (din2353): Not applicable
Tube diameter 2: Not applicable
Thread type (connection 2): BSPP
Connection type 2: Internal thread
Connection size 2: 1/4"
Dash size (connection 1): Not applicable
Series connection 1 (din 2353): Not applicable
Tube diameter 1: Not applicable
Thread type (connection 1): BSPP

Brand SKF
01900124
EAN 7316570466867
Supplier number SKF LAPA 45
