SKF

SKF HMV 54E hydraulic nut M270x4

4,160.95 tax incl.
€3,438.80 excl. VAT (incl. all environmental contributions)
On order: delivered from 27/05/2026
each

  • Ordered before 20:00 - delivered as of 27/05/2026
  • Free shipping
  • Delivery by DHL

Product description

Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.

  • Quick connection coupling can be fitted on the face or side of the nut
  • A spare set of piston seals and maintenance kit is included
  • Supplied with a quick connection coupling to fit the SKF hydraulic pumps
  • Equipped with eyebolts, two tommy bars and four mating holes on their front face
Key features according to our expert
  • Outer diameter: 368 mm
  • Width: 48 mm
  • Thread nominal size*: Tr270 x 4
Specifications / All features
  • Brand: SKF
  • EAN: 7316577080158
  • Supplier number: SKF HMV 54E
Outer diameter
368 mm
Width
48 mm
Thread nominal size*
Tr270 x 4
Thread form
ISO 2901-1977 tolerance class 7H
Piston area
19800
Maximum piston displacement
12
Connecting thread
Tr 270x4
Piston outer diameter
352
Piston width
9
Piston inner diameter
272
Product weight
20.5
Model
Metric thread
Outside diameter
368
Maximum pressure
80
