SKF HMV 106E hydraulic nut M530x6

9,642.40 tax incl.
€7,968.93 excl. VAT (incl. all environmental contributions)
On order: delivered from 27/05/2026
each

  • Ordered before 20:00 - delivered as of 27/05/2026
  • Free shipping
  • Delivery by DHL

Product description

Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.

  • Quick connection coupling can be fitted on the face or side of the nut
  • A spare set of piston seals and maintenance kit is included
  • Supplied with a quick connection coupling to fit the SKF hydraulic pumps
  • Equipped with eyebolts, two tommy bars and four mating holes on their front face
Key features according to our expert
  • Outer diameter: 670 mm
  • Width: 69 mm
  • Thread nominal size*: Tr530 x 6
Specifications / All features
  • Brand: SKF
  • EAN: 7316577080189
  • Supplier number: SKF HMV 106E
Outer diameter
670 mm
Width
69 mm
Thread nominal size*
Tr530 x 6
Thread form
ISO 2901-1977 tolerance class 7H
Piston area
56200
Maximum piston displacement
21
Connecting thread
Tr 530x6
Piston outer diameter
645
Piston width
13
Piston inner diameter
532
Product weight
79
Model
Metric thread
Outside diameter
670
Maximum pressure
250
