SKF

SKF FYJ 513 bearing housing with square flanges for insert bearing, cast iron, JIS

Recommended Retail Price €207.20
102.40 tax incl.
€84.63 excl. VAT (incl. all environmental contributions)
On order: delivered from 28/05/2026
each

  • Ordered before 20:00 - delivered as of 28/05/2026
  • Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL

Product description

These square flanged housings for insert bearings are complaint with Japanese Industrial Standards (JIS). They are made of grey cast iron and can be bolted with four bolts to a machine wall or frame. They have been developed for bearing arrangements that must operate reliably in difficult environments.

  • Resist high levels of contamination
  • Accommodate relatively heavy loads
Key features according to our expert
  • Seat diameter: 120 mm
  • Material (bearing housing): Cast iron
  • Shape (bearing housing): Square
Specifications / All features
  • Brand: SKF
  • EAN: 7316570947571
  • Supplier number: SKF FYJ 513
Seat diameter
120 mm
Material (bearing housing)
Cast iron
Shape (bearing housing)
Square
Fastening bolt hole type
Plain
Grease fitting
With
Spherical seating diameter
120
Housing type
Flanged
Flanged housing type
Square
Number of bolt holes for fasteners
4
Centre distance between bolt holes
149
Housing overall width
50
Relubrication hole
With
Coating
Without
Material, housing
Cast iron
