Is the insert bearing included with this housing?

No, this product is the housing only. You pair it with a compatible SKF insert bearing.

What is the spherical seating diameter of the SKF FY 512 M?

The spherical seating diameter of this housing is 110 mm.

What material is this bearing housing made from?

This square flanged housing is made of durable cast iron.

How is this housing mounted?

You mount it using 4 attachment bolts with a centre distance of 143 mm to a machine wall or frame.

Does the housing feature a relubrication facility?

Yes, it comes equipped with a relubrication hole and a grease fitting for maintenance.

SKF FY 512 M bearing housing with square flanges for insert bearings, cast iron

Supplier number: SKF FY 512 M | EAN 7316571176192

Recommended Retail Price €133.67

65.95 tax incl.

€54.50 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Ordered before 20:00 - delivered as of 12/10/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Rigid mounting with Skf FY 512 M

Practical benefits

Durable cast iron housing: Heavy-duty cast iron construction absorbs high mechanical loads and resists tough operating conditions reliably.
Stable four-bolt flange mounting: You secure the square housing firmly to machine frames or walls with balanced four-point support.
Integrated relubrication feature: The built-in grease fitting allows you to lubricate the insert bearing quickly without disassembling your setup.

In a nutshell

The right choise for

With the Skf fy 512 M flanged housing, you gain a rigid and dependable mounting interface for rotating shafts on machine frames and walls. Manufactured from durable cast iron, this square housing easily absorbs heavy mechanical loads and severe vibration. The four-bolt flange configuration allows you to secure the unit firmly with balanced stability. Featuring a 110 mm spherical seating diameter, it provides a precise fit for a compatible insert bearing. In addition, the integrated grease fitting and relubrication hole make routine maintenance fast and straightforward without disassembling your setup.

Product information FAQ

€65.95

In stock - tax incl.

Key features according to our expert

Seat diameter: 110 mm
Material (bearing housing): Cast iron
Shape (bearing housing): Square

Product description

These square flanged housings for insert bearings are made of grey cast iron and can be bolted with four bolts to a machine wall or frame. They have been developed for bearing arrangements that must operate reliably in difficult environments.

Resist high levels of contamination
Accommodate relatively heavy loads

Documents

⤓ Technical data sheet PDF

All Features

Seat diameter: 110 mm
Material (bearing housing): Cast iron
Shape (bearing housing): Square
Fastening bolt hole type: Plain
Grease fitting: With
Spherical seating diameter: 110
Housing type: Flanged
Flanged housing type: Square
Number of bolt holes for fasteners: 4
Centre distance between bolt holes: 143
Housing overall width: 52
Relubrication hole: With
Coating: Without
Material, housing: Cast iron

Brand SKF
01190835
EAN 7316571176192
Supplier number SKF FY 512 M

Frequently asked questions about this product

Answered by specialists

Is the insert bearing included with this housing?: No, this product is the housing only. You pair it with a compatible SKF insert bearing.
What is the spherical seating diameter of the SKF FY 512 M?: The spherical seating diameter of this housing is 110 mm.
What material is this bearing housing made from?: This square flanged housing is made of durable cast iron.
How is this housing mounted?: You mount it using 4 attachment bolts with a centre distance of 143 mm to a machine wall or frame.
Does the housing feature a relubrication facility?: Yes, it comes equipped with a relubrication hole and a grease fitting for maintenance.
