What are the dimensions of this SKF spherical roller bearing?

The bearing has a 30 mm bore diameter, 62 mm outer diameter, and 25 mm width.

What type of bore does the SKF BS2-2206-2RS/VT143 have?

This model features a cylindrical bore for direct mounting onto a 30 mm shaft.

Is this spherical roller bearing sealed?

Yes, it is equipped with rubber contact seals on both sides (2RS).

Can this sealed bearing be relubricated?

Yes, the bearing design includes features that allow for relubrication.

SKF BS2-2206-2RS/VT143 double-row cylindrical roller bearing 30 x 62 x 25 mm

Supplier number: SKF BS2-2206-2RS/VT143 | EAN 7316576193194

Recommended Retail Price €258.95

127.95 tax incl.

€105.74 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Ordered before 20:00 - delivered as of 16/10/2026
Free shipping
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Robust performance under heavy loads

Practical benefits

High radial load capacity: With two rows of symmetrical rollers, you can handle high radial and axial loads in demanding applications.
Smooth self-aligning operation: The spherical design compensates for shaft deflection and angular misalignment without increasing operating friction or temperature.
Reliable double contact seals: Equipped with rubber seals, this Skf roller bearing prevents contamination and keeps grease securely inside.

In a nutshell

The right choise for

With the Skf BS2-2206-2RS/VT143 double-row spherical roller bearing, you keep heavy machinery running reliably under demanding conditions. Its two rows of rollers effortlessly handle high radial and simultaneous axial loads. The self-aligning design automatically compensates for shaft deflections and angular misalignment, preventing unnecessary friction and stress. Featuring a 30 mm cylindrical bore, a 62 mm outer diameter, and a 25 mm width, it mounts directly onto straight shafts. Integrated double contact rubber seals protect internal components against dust and contaminants, while the relubrication features allow straightforward routine maintenance to maximize machine uptime and service life.

Product information FAQ

€127.95

In stock - tax incl.

Key features according to our expert

Inner diameter: 30 mm
Width: 25 mm
Number of rows: 2
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber
Radial clearance: CN (Normal)
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 62 mm

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. Under normal operating conditions, sealed bearings are almost maintenance-free, keeping service costs and grease consumption low. The design includes features to facilitate relubrication.

Accommodate misalignment
High load carrying capacity
Sealed for increased reliability, with relubrication features
Low friction and long service life
Increased wear resistance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 30 mm
Width: 25 mm
Number of rows: 2
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber
Radial clearance: CN (Normal)
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 62 mm
Skf performance class: SKF Explorer
Basic static load rating: 58.5
Relubrication feature: With
Tolerance class for run-out: P5
Lubricant: Grease
Sealing type: Contact
Cage: Sheet metal
Locating feature, bearing outer ring: Without
Radial internal clearance: CN
Basic dynamic load rating: 66.1
Sealing: Seal on both sides
Limiting speed: 5200
Bore diameter: 30
Outer diameter: 62
Tolerance class for dimensions: Normal

Brand SKF
01991866
EAN 7316576193194
Supplier number SKF BS2-2206-2RS/VT143

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this SKF spherical roller bearing?: The bearing has a 30 mm bore diameter, 62 mm outer diameter, and 25 mm width.
What type of bore does the SKF BS2-2206-2RS/VT143 have?: This model features a cylindrical bore for direct mounting onto a 30 mm shaft.
Is this spherical roller bearing sealed?: Yes, it is equipped with rubber contact seals on both sides (2RS).
Can this bearing accommodate misalignment?: Yes, the double-row spherical design automatically compensates for shaft deflections and angular misalignment.
Can this sealed bearing be relubricated?: Yes, the bearing design includes features that allow for relubrication.
