SKF 22332 CC/W33 double-row cylindrical roller bearing 160 x 340 x 114 mm

Recommended Retail Price €6,583.85
3,259.60 tax incl.
€2,693.88 excl. VAT (incl. all environmental contributions)
On order: delivered from 28/05/2026
each

  • Ordered before 20:00 - delivered as of 28/05/2026
  • Free shipping
  • Delivery by DHL

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

  • Accommodate misalignment
  • High load carrying capacity
  • Relubrication features
  • Low friction and long service life
  • Increased wear resistance
Key features according to our expert
  • Inner diameter: 160 mm
  • Width: 114 mm
  • Number of rows: 2
  • Seal (bearing): Without seal
  • Material (bearing seal): Not applicable
  • Radial clearance: CN (Normal)
  • Material (cage): Brass (sheet)
  • Bore type: Cylindrical
  • Outer diameter: 340 mm
Specifications / All features
  • Brand: SKF
  • EAN: 7316576603259
  • Supplier number: SKF 22332 CC/W33
Inner diameter
160 mm
Width
114 mm
Number of rows
2
Seal (bearing)
Without seal
Material (bearing seal)
Not applicable
Radial clearance
CN (Normal)
Material (cage)
Brass (sheet)
Bore type
Cylindrical
Outer diameter
340 mm
Skf performance class
SKF Explorer
Basic static load rating
1960
Relubrication feature
With
Reference speed
1500
Candidate for remanufacturing
Yes
Lubricant
None
Cage
Sheet metal
Locating feature, bearing outer ring
Without
Tolerance class for run-out
P5
Radial internal clearance
CN
Basic dynamic load rating
1680
Sealing
Without
Limiting speed
1900
Bore diameter
160
Outside diameter
340
Tolerance class for dimensions
Normal
