SKF 22313 E spherical roller bearing cylindrical 65 x 140 x 48 mm

Supplier number: SKF 22313 E | EAN 7316576653841

Recommended Retail Price €641.91

317.80 tax incl.

€262.64 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Ordered before 20:00 - delivered tomorrow 29/09/2026
Free shipping
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Heavy load capacity with self-alignment

Practical benefits

High load carrying capacity: You accommodate heavy radial and axial loads simultaneously thanks to the robust double row spherical roller design.
Self-aligning Skf 22313 E: The bearing compensates for shaft deflection and misalignment without increasing friction or operational temperature.
Simplified relubrication feature: You reduce maintenance downtime and component wear by easily replenishing lubricant directly through the integrated relubrication features.

In a nutshell

The right choise for

Keep your heavy industrial machinery running smoothly with the Skf 22313 e double row spherical roller bearing. Designed with a 65 mm cylindrical bore, this robust bearing effortlessly accommodates high radial and axial loads simultaneously. Its self-aligning design automatically compensates for shaft deflection and misalignment without generating excessive friction or temperature rise. Integrated relubrication features allow you to supply fresh lubricant directly to the raceways, minimizing wear and extending maintenance intervals. This ensures dependable, continuous operation and prevents costly downtime across demanding drivetrain and rotating equipment applications.

Product information FAQ

€317.80

In stock - tax incl.

Key features according to our expert

Inner diameter: 65 mm
Width: 48 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: CN (Normal)
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 140 mm

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 65 mm
Width: 48 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: CN (Normal)
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 140 mm
Reference speed: 3800
Basic static load rating: 360
Relubrication feature: With
Tolerance class for run-out: P5
Skf performance class: SKF Explorer
Lubricant: None
Cage: Sheet metal
Locating feature, bearing outer ring: Without
Radial internal clearance: CN
Basic dynamic load rating: 357
Sealing: Without
Limiting speed: 5000
Bore diameter: 65
Outside diameter: 140
Tolerance class for dimensions: Normal

Brand SKF
01090085
EAN 7316576653841
Supplier number SKF 22313 E

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this SKF bearing?: It has an inside diameter of 65 mm, an outside diameter of 140 mm, and a width of 48 mm.
What bore type does this bearing have?: This bearing features a cylindrical bore for direct mounting on a straight shaft.
Can this bearing be relubricated?: Yes, this spherical roller bearing is equipped with relubrication features.
What internal radial clearance does this model have?: This model has a normal radial internal clearance (CN).
Does this SKF bearing include built-in seals?: No, this is an open bearing without seals.
