What are the dimensions of this bearing?

The bearing has a 60 mm bore, a 130 mm outside diameter, and a width of 46 mm.

What bore type does the SKF 22312 E feature?

This bearing has a cylindrical (straight) bore for mounting directly onto a shaft.

What internal radial clearance does this bearing have?

It features standard normal radial internal clearance (designated as CN).

Does this bearing come with integrated seals?

No, this is an open bearing without built-in seals.

Does this bearing support relubrication?

Yes, this double-row spherical roller bearing includes features to facilitate relubrication.

SKF 22312 E spherical roller bearing cylindrical 60 x 130 x 46 mm

Supplier number: SKF 22312 E | EAN 7316576653735

Recommended Retail Price €552.03

273.20 tax incl.

€225.79 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Ordered before 20:00 - delivered as of 16/10/2026
Free shipping
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Dependable performance under heavy loads

Practical benefits

Skf 22312 E bearing: You can handle heavy radial loads and shaft deflections smoothly with this self-aligning spherical roller bearing design.
Simplified relubrication process: The integrated relubrication features allow you to replenish lubricant efficiently, keeping machine downtime to a minimum.
Durable low friction cage: Built with a robust metal cage, it reduces friction and heat generation for prolonged service life during continuous operation.

In a nutshell

The right choise for

Keep your heavy-duty industrial machinery running reliably with the Skf 22312 e double-row spherical roller bearing. Engineered with a cylindrical bore (60 x 130 x 46 mm) and normal radial internal clearance (CN), this open bearing effortlessly accommodates severe shaft deflections and angular misalignment without increasing friction. Its durable sheet metal cage ensures smooth operation under heavy radial loads, while integrated relubrication features simplify routine maintenance. You minimize costly downtime and extend machine service life across demanding conveyor drives, gearboxes, and processing equipment.

Product information FAQ

€273.20

In stock - tax incl.

Key features according to our expert

Inner diameter: 60 mm
Width: 46 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: CN (Normal)
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 130 mm

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 60 mm
Width: 46 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: CN (Normal)
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 130 mm
Reference speed: 4000
Basic static load rating: 335
Relubrication feature: With
Tolerance class for run-out: P5
Skf performance class: SKF Explorer
Lubricant: None
Cage: Sheet metal
Locating feature, bearing outer ring: Without
Radial internal clearance: CN
Basic dynamic load rating: 325
Sealing: Without
Limiting speed: 5300
Bore diameter: 60
Outer diameter: 130
Tolerance class for dimensions: Normal

Brand SKF
01090083
EAN 7316576653735
Supplier number SKF 22312 E

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this bearing?: The bearing has a 60 mm bore, a 130 mm outside diameter, and a width of 46 mm.
What bore type does the SKF 22312 E feature?: This bearing has a cylindrical (straight) bore for mounting directly onto a shaft.
What internal radial clearance does this bearing have?: It features standard normal radial internal clearance (designated as CN).
Does this bearing come with integrated seals?: No, this is an open bearing without built-in seals.
Does this bearing support relubrication?: Yes, this double-row spherical roller bearing includes features to facilitate relubrication.
