SKF 22308 E double-row cylindrical roller bearing 40 x 90 x 33 mm

Supplier number: SKF 22308 E | EAN 7316571570518

Recommended Retail Price €310.38

153.60 tax incl.

€126.94 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 3 products in stock.

Ordered before 20:00 - delivered as of 30/09/2026
Free shipping
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Reliable heavy performance with Skf

Practical benefits

High load carrying capacity: You accommodate heavy radial and axial loads in both directions with the robust two-row spherical design.
Integrated relubrication features: You simplify routine maintenance and keep operation smooth using the built-in lubrication groove and holes.
Automatic self aligning capability: You handle shaft deflections and angular misalignments without experiencing increased friction or temperature rise.

In a nutshell

The right choise for

With the Skf 22308 e double-row spherical roller bearing, you keep heavy industrial rotating machinery running smoothly and reliably. Thanks to its self-aligning design, this open bearing accommodates shaft deflections and angular misalignment without increasing friction. The two-row layout delivers high radial and double-direction axial load capacity, making it well suited for demanding drive shafts and conveyor systems. Featuring dimensions of 40 x 90 x 33 mm and a cylindrical bore, it mounts directly onto the shaft. Built-in relubrication grooves and holes simplify routine maintenance, ensuring your mechanical equipment delivers a long and trouble-free service life.

Product information FAQ

€153.60

In stock - tax incl.

Key features according to our expert

Inner diameter: 40 mm
Width: 33 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: CN (Normal)
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 90 mm

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 40 mm
Width: 33 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: CN (Normal)
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 90 mm
Reference speed: 6000
Basic static load rating: 140
Relubrication feature: With
Tolerance class for run-out: P5
Skf performance class: SKF Explorer
Lubricant: None
Cage: Sheet metal
Locating feature, bearing outer ring: Without
Radial internal clearance: CN
Basic dynamic load rating: 155
Sealing: Without
Limiting speed: 8000
Bore diameter: 40
Outside diameter: 90
Tolerance class for dimensions: Normal

Brand SKF
01090299
EAN 7316571570518
Supplier number SKF 22308 E

Frequently asked questions about this product

Answered by specialists

What are the exact dimensions of this bearing?: This bearing has a bore diameter of 40 mm, an outside diameter of 90 mm, and a width of 33 mm.
Is this SKF spherical roller bearing self-aligning?: Yes, its double-row design accommodates shaft deflections and angular misalignment without increased friction.
Does this bearing have relubrication features?: Yes, the outer ring features an annular lubrication groove and lubrication holes for easy relubrication.
What type of bore and clearance does the SKF 22308 E have?: It features a cylindrical bore for direct shaft mounting and a standard normal radial internal clearance (CN).
Is this bearing sealed?: No, this is an open bearing without integrated seals, designed for use with external lubrication in a housing.
