SKF 22216 E/C3 double-row cylindrical roller bearing 80 x 140 x 33 mm

Supplier number: SKF 22216 E/C3 | EAN 7316576652509

Recommended Retail Price €505.60

250.20 tax incl.

€206.78 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 3 products in stock.

Ordered before 20:00 - delivered tomorrow 29/09/2026
Free shipping
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

High load capacity for demanding industrial machinery

Practical benefits

High radial load capability: The double-row spherical design allows you to handle heavy radial and axial loads reliably during continuous operation.
Smooth self-aligning operation: You prevent premature wear because the internal geometry automatically accommodates shaft deflections and angular misalignments.
Relubricable Skf spherical bearing: With dedicated lubrication holes and grooves, you can grease the bearing directly to maximize service intervals and efficiency.

In a nutshell

The right choise for

With the Skf 22216 E/C3 double-row spherical roller bearing, you keep heavy-duty industrial machinery running reliably. Its self-aligning design handles heavy radial and axial loads while automatically compensating for shaft deflections and angular misalignments without increasing friction. The C3 radial internal clearance prevents excessive heat buildup and thermal expansion during continuous operation at elevated temperatures. Featuring dimensions of 80 x 140 x 33 mm and a cylindrical bore, this open bearing mounts directly onto your shaft. Thanks to integrated relubrication features, you can add fresh lubricant during regular maintenance to maximize service life and minimize downtime.

Product information FAQ

€250.20

In stock - tax incl.

Key features according to our expert

Inner diameter: 80 mm
Width: 33 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: C3
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 140 mm

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 80 mm
Width: 33 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: C3
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 140 mm
Reference speed: 4300
Basic static load rating: 270
Relubrication feature: With
Tolerance class for run-out: P5
Skf performance class: SKF Explorer
Lubricant: None
Cage: Sheet metal
Locating feature, bearing outer ring: Without
Radial internal clearance: C3
Basic dynamic load rating: 243
Sealing: Without
Limiting speed: 6000
Bore diameter: 80
Outside diameter: 140
Tolerance class for dimensions: Normal

Brand SKF
01090365
EAN 7316576652509
Supplier number SKF 22216 E/C3

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this SKF spherical roller bearing?: This bearing has an inside diameter of 80 mm, an outside diameter of 140 mm, and a width of 33 mm.
What does the C3 designation mean?: C3 indicates greater radial internal clearance than standard, which accommodates higher operating temperatures.
Can this bearing be relubricated?: Yes, it includes relubrication features allowing you to add fresh lubricant directly during maintenance.
Is this spherical roller bearing sealed?: No, it is an open bearing without integrated seals, designed for use in lubricated housing systems.
What bore type does this bearing have?: It features a cylindrical bore for direct mounting onto a cylindrical shaft.
