SKF 22215 EK/C4 spherical roller bearing tapered roller 75 x 130 x 31 mm

Supplier number: SKF 22215 EK/C4 | EAN 7316576652455
This product has been discontinued.



Product information

Key features according to our expert

  • Inner diameter: 75 mm
  • Width: 31 mm
  • Number of rows: 2
  • Sealing (bearing): Without seals
  • Material (bearing seal): Not applicable
  • Radial clearance: C4
  • Material (cage): Brass (sheet)
  • Bore type: Tapered
  • Outer diameter: 130 mm

Product description:

  • Spherical roller bearings, also called pendulum roller bearings, have two rows of rollers with a common spherical raceway in the outer ring
  • The two raceways of the inner ring are at an angle to the centre line of the shaft
  • The bearings can adjust and are therefore insensitive to shaft misalignment relative to the housing and to shaft deflection
  • Spherical roller bearings can support not only high radial loads but also axial loads in both directions

Documents

All Features

Inner diameter
75 mm
Width
31 mm
Number of rows
2
Sealing (bearing)
Without seals
Material (bearing seal)
Not applicable
Radial clearance
C4
Material (cage)
Brass (sheet)
Bore type
Tapered
Outer diameter
130 mm
Basic static load rating
240 kN
Locating feature, bearing outer ring
Without
Tolerance class
Normal
Radial internal clearance
C4
Lubricant
None
Relubrication feature
With
Reference speed
4,800 r/min
Skf performance class
SKF Explorer
Tolerance class for dimensions
Normal
Cage
Sheet metal
Sealing
Without
Basic dynamic load rating
217 kN
Limiting speed
6,300 r/min
Tolerance class for run-out
P5
Bore diameter
75 mm
Outside diameter
130 mm
  • Brand SKF
  • EAN 7316576652455
  • Supplier number SKF 22215 EK/C4
