What are the dimensions of this SKF spherical roller bearing?

This bearing has a 65 mm bore diameter, a 120 mm outside diameter, and a width of 31 mm.

What does the C3 designation indicate for this bearing?

The C3 clearance class means the bearing has a greater radial internal clearance than standard, suited for thermal expansion.

Does this bearing have a cylindrical or tapered bore?

This model features a cylindrical bore for direct mounting onto a straight shaft.

Can this bearing be relubricated?

Yes, it is equipped with relubrication features, including lubrication holes and a groove in the outer ring.

Is this SKF bearing sealed?

No, this spherical roller bearing is an open type without built-in seals.

SKF 22213 E/C3 spherical roller bearing cylindrical 65 x 120 x 31 mm

Supplier number: SKF 22213 E/C3 | EAN 7316571560908

Recommended Retail Price €354.80

175.60 tax incl.

€145.12 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 3 products in stock.

Ordered before 20:00 - delivered tomorrow 15/10/2026
Free shipping
Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Heavy load support for industrial shafts

Practical benefits

High radial load capacity: The double row roller design allows you to handle heavy combined radial and axial forces reliably.
Automatic self-aligning compensation: It accommodates shaft deflections and misalignment smoothly without causing unnecessary friction or excessive heat buildup.
Simple relubrication and C3 clearance: Built-in lubrication features and extended C3 internal clearance ensure dependable running performance under elevated operating temperatures.

In a nutshell

The right choise for

Keep your heavy machinery operating reliably with the Skf 22213 E/C3 spherical roller bearing. Engineered with two rows of rollers, it handles heavy combined radial and axial loads in both directions with ease. Its self-aligning design effortlessly compensates for shaft deflections and angular misalignment without increasing friction or heat. Measuring 65 mm inside diameter, 120 mm outside diameter, and 31 mm in width, the cylindrical bore mounts straight onto the shaft. The increased C3 radial internal clearance prevents binding during thermal expansion, while integrated relubrication features simplify maintenance to extend service life.

Product information FAQ

€175.60

In stock - tax incl.

Key features according to our expert

Inner diameter: 65 mm
Width: 31 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: C3
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 120 mm

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 65 mm
Width: 31 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: C3
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 120 mm
Reference speed: 5000
Basic static load rating: 216
Relubrication feature: With
Tolerance class for run-out: P5
Skf performance class: SKF Explorer
Lubricant: None
Cage: Sheet metal
Locating feature, bearing outer ring: Without
Radial internal clearance: C3
Basic dynamic load rating: 198
Sealing: Without
Limiting speed: 7000
Bore diameter: 65
Outer diameter: 120
Tolerance class for dimensions: Normal

Brand SKF
01090359
EAN 7316571560908
Supplier number SKF 22213 E/C3

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this SKF spherical roller bearing?: This bearing has a 65 mm bore diameter, a 120 mm outside diameter, and a width of 31 mm.
What does the C3 designation indicate for this bearing?: The C3 clearance class means the bearing has a greater radial internal clearance than standard, suited for thermal expansion.
Does this bearing have a cylindrical or tapered bore?: This model features a cylindrical bore for direct mounting onto a straight shaft.
Can this bearing be relubricated?: Yes, it is equipped with relubrication features, including lubrication holes and a groove in the outer ring.
Is this SKF bearing sealed?: No, this spherical roller bearing is an open type without built-in seals.
