Product Description:
- Phantom HSS Annular Cutter cutting depth 55 mm
- Long series, Weldon type diam. 19 mm and quick change shank
Supplier number:
PHANTOM 621502500
|
EAN
8716563238140
56.60
tax incl.
€46.78 excl. VAT (incl. all environmental contributions)
Clean drilling with the Phantom core drill
Practical benefits- Deep cutting capacity in metal: With a 55 mm cutting depth, you bore smoothly through thick structural steel workpieces.
- High heat and wear resistance: The premium HSS-EX steel ensures long tool life and maintains sharpness under heavy drilling loads.
- Secure fit during operation: The WELDON-19 shank gives you stable clamping and reliable torque transfer on magnetic drilling machines.
In a nutshell
The right choise forWith the Phantom 621502500 hss-ex core drill, you bore clean 25 mm holes in metal and structural steel quickly and accurately. Thanks to its 55 mm cutting depth, you power through thick workpieces without the need for pilot drilling. The premium hss-ex steel delivers outstanding heat and wear resistance, maintaining sharpness and extended tool life under demanding metalworking conditions. Equipped with a standard WELDON-19 shank, it provides secure clamping and reliable torque transfer on your magnetic drill press or pillar drill. This allows you to produce accurate, burr-free holes with full control and maximum efficiency on every job.
Product information
Key features according to our expert
- Diameter: 25 mm
- Connection profile: Weldon
- For material: Metal
- Cutting length: 55 mm
All Features
- Diameter
- 25 mm
- Connection profile
- Weldon
- For material
- Metal
- Cutting length
- 55 mm
- Surface
- Bright
- Drill diameter (d1)
- 25 mm
- Shank (d2)
- 19 mm
- Tolerance d1 (tol. d1)
- h11
- Cutting depth (ap)
- 55 mm
- Shank type
- Weldon
- Tool material
- HSS-EX
- Brand PHANTOM
- EAN 8716563238140
- Supplier number PHANTOM 621502500
Frequently asked questions about this product
Answered by specialists
- What are the diameter and cutting depth of this core drill?
- This core drill has a drilling diameter of 25 mm and a cutting depth of 55 mm.
- What type of shank does the Phantom 621502500 have?
- It features a standard Weldon 19 mm (3/4") shank.
- Which materials is this HSS-EX core drill suitable for?
- It is designed for drilling metal, including alloyed and non-alloyed steel.
- Which machines can this core drill be used with?
- You can use it on magnetic drilling machines or drill presses equipped with a compatible Weldon arbor.
