Precise edge rounding with consistent results

Practical benefits

Perfect radius in one step: You create an exact 3 mm outer radius along metal edges without damaging surrounding surfaces.
Smooth and chatter-free operation: The high concentricity prevents impact marks and significantly reduces wear on your tool drive.
Reliable Pferd carbide build: The specialized EDGE tooth geometry gives you maximum guidance and control on tough metals.

In a nutshell

The right choise for

With the Pferd V 1612/6 edge R3,0 carbide rounding burr, you shape and finish metal edges with consistent precision in a single step. Eliminate sharp edges and manual filing by directly machining a uniform 3 mm outer radius, significantly improving edge adhesion for anti-corrosion coatings. The specialized edge tooth geometry ensures smooth, controlled guidance across steel, hardened steel, cast iron, and non-ferrous metals without damaging the workpiece. High concentricity prevents chatter marks and impact stress, reducing wear on both your burr and straight die grinder. Featuring a 16x12 mm head and a 6 mm cylindrical shank, it delivers professional contouring with complete control.

Product information FAQ

€167.85

tax incl.

Key features according to our expert

Diameter: 16 mm
Shape (burr cutter): Special
Cutting length: 12 mm
Shank type: Cylindrical
Shank size (milling cutter): 6 mm

Product description

PFERD Tungsten carbide concave radius burr EDGE V dia. 16x12 mm shank dia. 6 mm work on edges

Characteristics

Tungsten carbide burrs with the EDGE cut have been especially developed for defined work on edges
The special design allows the burr to run directly along the edges without damaging the workpiece
In just one step, it is possible to achieve precise edge shapes
Among other things, rounding edges is a precautionary measure for anti-corrosion protection according to: ISO 129443, ISO 85013, SOLAS XII/6,3 (Ref
T4/3,01 MSC
1/Circ
1198)
Concave radius burrs for the production of precise radii
Suitable for the production and processing of 3 mm outer radii

Advantages:

Special design for precise guidance.
Safe and comfortable to guide.
Creates exact edge shapes in one single step.
The highly accurate concentricity enables impactfree working without creating chatter marks. This considerably reduces wear on the tool and tool drive.

All Features

Diameter: 16 mm
Shape (burr cutter): Special
Cutting length: 12 mm
Shank type: Cylindrical
Shank size (milling cutter): 6 mm
Rpm up to, hardened refined steels above 1,200 n/mm²: 15000
Rpm up to, hard non-ferrous metals: 7000
Rpm of, soft non-ferrous metals: 12000
Rpm of, steels up to 1,200 n/mm²: 12000
Rpm of, hard non-ferrous metals: 5000
Length, construction: 12
Gearing: EDGE
Rpm up to, soft non-ferrous metals: 18000
Rpm up to, steels up to 1,200 n/mm²: 18000
Rpm of, heat-resistant materials: 5000
Rpm of, hardened refined steels above 1,200 n/mm²: 12000
Rpm van, grey cast iron, white cast iron: 12000
Processing tasks: Corners
Workable materials: Annealed cast iron
Length, toothed: 3
Rpm to, grey cast iron, white cast iron: 18000
ø shaft metric: 6
ø ball bearing: 10
Rpm to, heat-resistant materials: 9000

Brand PFERD
03235728
EAN 4007220952412
Supplier number PFERD 21152936

Frequently asked questions about this product

Answered by specialists

What is the Pferd V 1612/6 EDGE R3,0 burr used for?: This tungsten carbide burr is designed for precise edge radiusing and edge rounding with a fixed R3.0 mm radius.
What is the shank diameter of this burr?: It features a cylindrical 6 mm shank, suitable for straight die grinders with a 6 mm collet.
What are the dimensions of the burr head?: The head has an outer diameter of 16 mm and a cut length of 12 mm.
Which materials can be machined with the EDGE cut?: It is suitable for steel, hardened steel, cast iron, and non-ferrous metals.
What is the recommended technique for guiding this burr?: Guide the burr counter-rotationally along the edge, followed by a final pass in the direction of rotation for a fine finish.
