PFERD B 0613/3 Z3 PLUS tungsten carbide burr flame shape B 6x13mm 3mm universal medium with crosscut teeth - 21203633

Name: PFERD B 0613/3 Z3 PLUS tungsten carbide burr flame shape B 6x13mm 3mm universal medium with crosscut teeth - 21203633
Brand: PFERD
SKU: 03235695
Price: 28.6 EUR
Availability: PreOrder

28.60 tax incl.

€23.64 excl. VAT (incl. all environmental contributions)

PFERD B 0613/3 Z3 PLUS tungsten carbide burr flame shape B 6x13mm 3mm universal medium with crosscut teeth - 21203633

€28.60

On order: delivered from 26/05/2026

each

Ordered before 20:00 - delivered as of 26/05/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

Product information

Product description

PFERD Tungsten carbide burr flame B dia. 06x13 mm shank dia. 3 mm Z3P universal medium cross cut

Characteristics

Cut 3 PLUS is cross cut and especially well-suited to machining of cast iron, steel, stainless steel (INOX), nickel-based alloys and titanium alloys
It is characterized by its high stock removal rate
Tungsten carbide burrs for general applications are suitable for fine and coarse stock removal on the key materials used in industrial manufacturing
They provide a good stock removal rate and are not specific to a particular material
Flame-shaped burr according to ISO 7755/8 with cut conforming to DIN 8033

Advantages:

Good stock removal rate through optimum matching of tungsten carbide, geometry, cut and available coating.
Long tool life.
The highly accurate concentricity enables impactfree working without creating chatter marks. This considerably reduces wear on the tool and tool drive.
High surface quality.

Key features according to our expert

Diameter: 6 mm
Shape (burr cutter): Flame (H)
Cutting length: 13 mm
Shank type: Cylindrical
Shank size (milling cutter): 3 mm

Specifications / All features

Brand: PFERD
03235695
EAN: 4007220955499
Supplier number: PFERD 21203633

Diameter: 6 mm
Shape (burr cutter): Flame (H)
Cutting length: 13 mm
Shank type: Cylindrical
Shank size (milling cutter): 3 mm
Rpm to, grey cast iron, white cast iron: 32000
Workable materials 1: Black annealed cast iron (GTS, GJMB)
Processing tasks: Obtaining cut-outs
Processing tasks 3: Milling
Workable materials 12: Steel
Workable materials 16: Steel up to 700 N/mm² (< 220 HB)
Processing tasks 1: Deburring
Rpm up to, hardened refined steels above 1,200 n/mm²: 19000
Processing tasks 5: Machining of surfaces
ø outside metric: 6
Workable materials 3: Cast iron
Workable materials 14: Steel up to 1,200 N/mm² (< 38 HRC)
Workable materials 5: Cobalt-based alloys
Workable materials 10: Nickel-based alloys (e.g. Inconel and Hastelloy)
Rpm up to, hard non-ferrous metals: 19000
Rpm of, soft non-ferrous metals: 24000
Rpm of, hard non-ferrous metals: 13000
Rpm of, stainless and acid-resistant steels: 13000
Rpm van, grey cast iron, white cast iron: 24000
Gearing: 3 PLUS
Rpm up to, soft non-ferrous metals: 32000
Workable materials 7: Aluminium alloys hard
Workable materials 8: Hardened, heat-treated steels above 1,200 N/mm² (< 38 HRC)
Workable materials 9: Heat-resistant materials
Workable materials 2: High-speed steel
Workable materials: Annealed cast iron
Rpm to, stainless and acid-resistant steels: 19000
Workable materials 6: Grey/lamellar/nodular cast iron (GG/GJL, GGG/GJS)
Length, toothed: 13
Processing tasks 2: Levelling
Workable materials 4: Cast steel
Processing tasks 6: welding
Workable materials 18: White annealed cast iron (GTW, GJMW)
Workable materials 11: Stainless steel (INOX)
Workable materials 15: Steel above 700 N/mm² (> 220 HB)
Corner execution radius: 1
Length, total: 43
Processing tasks 4: Milling out
ø shaft metric: 3
Workable materials 17: Tool steel
Workable materials 13: Steel, cast steel
Rpm of, hardened refined steels above 1,200 n/mm²: 13000
