Scope of delivery
- 1x K551533 - Bottom plate 500 mm x 400 mm3x
- K551032 - Clamping claw
- 2x K551024 - Location pin Ø 12 mm x 13 mm2x
- K551025 - Location pin Ø 12 mm x 25 mm
- 2x K551026 - Location pin Ø 12 mm x 50 mm
- 2x K551027 - Location pin Ø 12 mm x 100 mm2x
- K551028 - Location pin Ø 20 mm x 13 mm2x
- K551029 - Location pin Ø 20 mm x 25 mm2x
- K551030 -
- Location pin Ø 20 mm x 50 mm2x
- K551031 - Location pin Ø 20 mm x 100 mm2x
- K551040 - Adjustable location pin Ø 20 mm2x
- K551041 - Adjustable location pin Ø 12 mm3x
- K551042 - Location pin Ø 12 mm with bore 6 mm3x
- K551043 - Location pin Ø 20 mm with bore 8 mm2x
- K551035 - Reception support small
- 1x K551036 - Reception support large
- 1x K551044 - Reception support L = 90 mm, Ø 12 mm2x
- K551045 - Reception bracket L = 120 mm, Ø 20 mm1x
- K551046 - Slotted nut for reception bracket h = 12 mm2x
- K551047 - Slotted nut for reception bracket h = 15 mm
- 2x K550262 - V-block mini, Ø12mm2x
- K550261 - Cone receiver mini, Ø12 mm1x
- K550250 - Stop element mini, Ø 6 mm1x
- K550247 - Back square mini, Ø 6 mm2x
- K550058 - V-block2x
- K550365 - Cone receiver1x
- K550982 - Stop element1x
- K550248 - Back square2x K550888
- - Straight pin Ø 6 mm x 20 mm2x
- K550889 - Straight pin Ø 6 mm x 30 mm2x
- K550890 -
- Straight pin Ø 6 mm x 40 mm
- 2x K550000 - Straight pin Ø 8 mm x 30 mm2x
- K550001 - Straight pin Ø 8 mm x 50 mm
- 2x K550002 - Straight pin Ø 8 mm x 65 mm
- 3x K550716 - Straight pin threaded, M6 x 75 mm2x
- K550279 - Spring clamp, Ø 8 mm, L = 60 mm1x
- K550554 - Spring clamp, Ø 8 mm, L = 40 mm
- 6x K550563 - Cylinder head screw M6 x 25 mm6x
- K550110 - Cylinder head screw M6 x 20 mm12x
- K550591 - Washer Ø 6,4 mm x Ø 17 mm1x
- K551050 - Allen spanner 2 mm1x
- K551051 - Allen spanner 3 mm1x
- K551052 - Allen spanner 4 mm1x
- K551053 - Allen spanner 5 mm1x
- K551054 - Double socket spanner 10-17
