Product description
- Single-acting, spring return
- Nitrocarbonised plunger for corrosion resistance
- Bearing surfaces with minimal friction
- Anti-extrusion seals for improved high-pressure performance
- Sleeve thread suitable for full load
- Grooved saddles fitted as standard on all models
- Capacity: 109 tonnes
- Stroke length: 254 mm
- Oil capacity: 3896 cm³
- Construction height: 375 mm
- Cylinder diameter: 185 mm
- Piston diameter: 114 mm
- Weight: 65.5 kg
- Max. working pressure: 700 bar
- Complete with quick-release coupling
