GEDORE QUICKSET MINOR FH LB torque screwdriver 1/4" 24-120 cNm - 2282410

Name: GEDORE QUICKSET MINOR FH LB torque screwdriver 1/4" 24-120 cNm - 2282410
Brand: GEDORE
SKU: 08088292
Price: 249.8 EUR
Availability: PreOrder

Supplier number: GEDORE 2282410 | EAN 0701936219565

Recommended Retail Price €421.59

249.80 tax incl.

€206.45 excl. VAT (incl. all environmental contributions)

On order: delivered from 09/10/2026

Ordered before 20:00 - delivered as of 09/10/2026
Free shipping
Delivery by DHL

✆ Talk to a specialist

Accurate torque control for sensitive fastening

Practical benefits

Prevents damaging overtightening reliably: The precision slipping mechanism disengages noticeably once you reach the target torque, keeping sensitive threads and fasteners protected.
Gedore delivers repeatable accuracy: With a working accuracy of +/- 6%, you achieve consistent results across serial production, maintenance, and quality inspection tasks.
Standardized hex bit drive: The 1/4" internal hexagon holder allows you to swap standard bits quickly for versatile precision assembly work.

In a nutshell

The right choise for

With the Gedore Quickset Minor fh lb torque screwdriver, you achieve exact fastening control during delicate assembly tasks in precision mechanics, electronics, and instrument manufacturing. Its integrated slipping mechanism disengages noticeably the moment you reach the preset torque, reliably protecting sensitive threads and components against overtightening. With a working accuracy of +/- 6%, you can perform repeatable series assembly and quality inspection tasks in compliance with din en iso 6789-2:2017. The 1/4" internal hexagon drive allows fast bit changes, while the included 1/4" to 1/4" adapter no. 757-20 lets you connect socket wrenches effortlessly.

Product information FAQ

€249.80

tax incl.

Key features according to our expert

Min. tightening torque: 24 Nm
Bit holder size: 1/4 inch
Bit holder type: Internal hexagon
VDE approved: No
With safety colour code 1000V: No
ESD: No
Max. tightening torque: 120 Nm

Scope of delivery

Torque screwdriver type 756,1/4" - 1/4" adapter (no. 757-20),Models no. 757-06/-09 with additional transverse handle for easier work,Test certificate according to DIN EN ISO 6789-2:2017,Delivery in sturdy carton packaging

Product description

Application Controlled screw tightening in the range 2 - 12 lbf-in
Fast, controlled tightening, enables series production
Electrical and electronics industry and apparatus engineering and industrial production or in quality control
Design Adjustable torque screwdriver - with scale
With 1/4" hexagon socket for 1/4" bits according to DIN 3126 - C 6.3
With adapter also suitable for 1/4" socket spanners in accordance with DIN 3124
Accuracy +/- 6% tolerance of set scale value
Construction in accordance with DIN EN ISO 6789, traceable to national standards
Precision ball mechanism for controlled clockwise and anticlockwise tightening
Precision mechanism glides on noticeably when set value is reached
Automatic reset to initial position, 3 models in the range 0.24 - 9 N-m
Micrometer scale division 1 cNm or 0.1 Nm
Lightweight design through anodised aluminium handle
Scope of delivery Torque screwdriver type 756, 1/4" - 1/4" adapter (No. 757-20)
Models No. 757-06/-09 with additional transverse handle for easier work
Test certificate in accordance with DIN EN ISO 6789-22017
Supplied in sturdy cardboard packaging

All Features

Min. tightening torque: 24 Nm
Bit holder size: 1/4 inch
Bit holder type: Internal hexagon
Vde approved: No
With safety colour code 1000v: No
Esd: No
Max. tightening torque: 120 Nm
Fixed setting: No
Scale [lbf-in]: 0.1 lbf-in
Tightening direction: Left and right
Drive type/drive: Bit holder
Tightening torque (max.) [lbf-in].: 12 lbf-in
Test certificate: DIN EN ISO 6789-2:2017
Precision +/-: +/- 6 %
Drive adaptor, hexagonal [metric]: 6.3 mm
Drive mounting, hexagonal [inch]: 1/4"
Target groups: AutomotiveElectronics Industry Precision mechanics Military Service
T-handle available: No
Epa/esd version: No
Tightening torque (min.) [lbf-in].: 2 lbf-in
Turn-off mechanism: Slipping clutch
Scope: AssemblyProduction Quality control Series assembly Maintenance and repair
Overall length [mm]: 169 mm

Brand GEDORE
08088292
EAN 0701936219565
Supplier number GEDORE 2282410

Frequently asked questions about this product

Answered by specialists

What is the adjustable torque range of this torque screwdriver?: The adjustment range is 2 to 12 lbf.in (approximately 24 to 120 cNm or 0.24 to 1.2 Nm).
Which bits and sockets can be used with this screwdriver?: It features a 1/4" female hexagon drive compliant with DIN 3126 - C 6.3. The included adapter allows using 1/4" sockets.
How does this tool prevent overtightening?: A precision radial ball clutch slips noticeably once the preset torque is reached, preventing overtightening.
Is a calibration certificate included in the scope of delivery?: Yes, it comes with a test certificate compliant with DIN EN ISO 6789-2:2017.
Is this torque screwdriver certified for VDE or ESD applications?: No, this model is not VDE-approved, not 1000V insulated, and not ESD-safe.
