GEDORE ETQR 6 electronic torque spanner E-torc Q R 6 0.25-6 Nm 1/4" - 3034607

Name: GEDORE ETQR 6 electronic torque spanner E-torc Q R 6 0.25-6 Nm 1/4" - 3034607
Brand: GEDORE
SKU: 08088240
Price: 3855.95 EUR
Availability: PreOrder

Supplier number: GEDORE 3034607 | EAN 4002805936580

Recommended Retail Price €7,203.64

3,855.95 tax incl.

€3,186.74 excl. VAT (incl. all environmental contributions)

On order: delivered from 20/10/2026

Ordered before 20:00 - delivered as of 20/10/2026
Free shipping
Delivery by DHL

✆ Talk to a specialist

Product information

€3,855.95

tax incl.

Key features according to our expert

Min. tightening torque: 0,25 Nm
Bit holder size: 1/4 inch
Bit holder type: Internal hexagon
VDE approved: No
With safety colour code 1000V: No
ESD: No
Overall length: 236 mm
Max. tightening torque: 6 Nm

Scope of delivery

L-BOXX 136

Product description

Features Electr. torque angle Measuring tool in screwdriver shape, ergonomically designed handle, ideal for the controlled test/measurement of very small torques (>= 0.25 Nm)
LED indicator and confirmation button integrated in the handle, 1/4" hex key for direct insertion of the bit.
User interfaces Connection to the E-torc QR display via a cable available separately (ETQR connection cable 3066436)
Accuracy Factory calibration certificate according to DIN ISO 6789 type 1 class C
Calibration certificate DAKkS DKDR 3-7 Class 1 (optional)
Scope of delivery ETQR6 Measuring head Torque screwdriver
In GEDORE L-BOXX® 136 No. 1100 L, incl. calibration certificate

All Features

Min. tightening torque: 0,25 Nm
Bit holder size: 1/4 inch
Bit holder type: Internal hexagon
Vde approved: No
With safety colour code 1000v: No
Esd: No
Overall length: 236 mm
Max. tightening torque: 6 Nm
Head width 1 [mm].: 12.0 mm
Fixed setting: No
Drive type/drive: Bit holder
Drive hex [inch]: 1/4"
Torque (min.) [nm].: 0.25 Nm
Measuring accuracy of tightening torque: ± 1% Toleranz vom Ablesewert, ± 1 Digit
Precision +/-: +/- 1 %
Tightening direction: Left and right
Overall length [mm]: 236 mm
Graphic display: No
Analysis software: No
Target groups: AutomotiveElectronics Industry Construction and Commercial Vehicles Military Energy Mechanical Engineering Railway Service
Reach: 0
Measurement accuracy angular rotation: ±1% , min. ±1° auf 360° bei mind. 4°/sec.
Epa/esd version: No
Tightening torque (min.) [lbf-in].: 0.18 lbf-in
Tightening torque (max) [lbf-ft]: 4.4 lbf-ft
Torque range (min./max.) [nm].: 0.25 Nm - 6 Nm
Scope: FittingSeries assembly Production Quality control Maintenance and repair Analysis of bolted connections
Torque (max.) [nm].: 6 Nm
