What is the adjustable torque range of this torque wrench?

The adjustable torque range of the Gedore DMUK 200 is 40 to 200 Nm.

What drive size does the Gedore DMUK 200 feature?

This torque wrench features a 1/2" square drive with push-button release and ball lock.

How do you know when the set torque has been reached?

The wrench mechanism provides a clear tactile and audible click signal when the target torque is reached.

Is this torque wrench VDE certified for electrical work?

No, this torque wrench is not VDE certified or insulated for live electrical applications.

How do you adjust the torque on this model?

You adjust the torque manually using the analog scale in Nm on the handle.

GEDORE DMUK 200 torque spanner dremaster uk 1/2", 40-200 Nm - 2641313

Name: GEDORE DMUK 200 torque spanner dremaster uk 1/2", 40-200 Nm - 2641313
Brand: GEDORE
SKU: 02302319
Price: 324.8 EUR
Availability: PreOrder

Supplier number: GEDORE 2641313 | EAN 4002805931455

Recommended Retail Price €525.16

324.80 tax incl.

€268.43 excl. VAT (incl. all environmental contributions)

On order: delivered from 20/10/2026

Ordered before 20:00 - delivered as of 20/10/2026
Free shipping
Delivery by DHL

✆ Talk to a specialist

Accurate and controlled bolt tightening

Practical benefits

Clear tactile and audible click: You feel and hear a distinct release impulse as soon as the preset torque is reached.
Certified high tightening accuracy: Calibrated to a +/- 3 percent tolerance, it ensures your fastenings consistently meet strict professional requirements.
Sturdy Gedore tubular construction: The durable steel tube design with a 1/2" reversible ratchet withstands demanding daily assembly work.

In a nutshell

The right choise for

With the Gedore dmuk 200 Dremaster uk torque wrench, you tighten every bolted connection with complete control and precision. Ideal for fitting wheel bolts in the workshop or assembling industrial machinery, its adjustable range of 40 to 200 Nm ensures you always match manufacturer specifications. a tightening accuracy of +/- 3 percent prevents stripped threads and loose fastenings. You immediately know when the target torque is reached thanks to the clear tactile and audible click impulse. Featuring a sturdy tubular steel design and a 1/2" reversible ratchet, this tool gives you total confidence on every assembly job.

Product information FAQ

€324.80

tax incl.

Key features according to our expert

Max. tightening torque: 200 Nm
Drive profile size: 1/2"
Material ( torque tool): Aluminium alloy
VDE approved: No
With safety colour code 1000V: Not applicable
ESD: No
Display: Analogue
Overall length: 530 mm
Min. tightening torque: 40 Nm

Product description

Application Controlled screw tightening in the range 40 - 200 Nm / 30 - 150 lbf-ft
Adjustable, audible and tactile switch-off robust torque spanner with integrated ratchet
Design Classified according to DIN EN ISO 6789-22017 Type II Class A including traceable test certificate, calibrated to a maximum permissible deviation of +/- 3% and thus more accurate than the +/- 4% specified in the standard
For controlled clockwise tightening
With 1/2" changeable ratchet
Robust, lacquered tubular steel construction, with galvanised ratchet and high-quality plastic parts
Ergonomically shaped plastic handle with calibration aid
Switchover between main scale Nm and secondary scale lbf-ft for avoiding reading errors when setting the desired torque
With micrometer scale for Nm main scale for setting intermediate scale values
Automatic switch-off using audible and tactile signal
Ergonomic torque adjustment system with instruction symbol
Possibility of quick adjustment using a pin spanner, not included in scope of supply
Secure adjustment system

All Features

Max. tightening torque: 200 Nm
Drive profile size: 1/2"
Material ( torque tool): Aluminium alloy
Vde approved: No
With safety colour code 1000v: Not applicable
Esd: No
Display: Analogue
Overall length: 530 mm
Min. tightening torque: 40 Nm
Scale division [nm]: 10 Nm
Fixed setting: No
Drive type/drive: Ratchet with gear ratchet
Tightening torque (min.) [lbf-ft]: 30 lbf-ft
Head width 1 [mm].: 42.5 mm
Test certificate: DIN EN ISO 6789-2:2017
Tightening direction: Turn right
Head height 1 [mm]: 22 mm
Precision +/-: +/- 3 %
Storage/contents: Plastic box
Tightening range (min/max) [lbf-ft].: 30 lbf-ft - 150 lbf-ft
Overall length [mm]: 530 mm
Retrieval angle: 7,5 °
Torque (min.) [nm].: 40 Nm
Vernier nm: 1 Nm
Turn-off mechanism: Short road clearance
Drive square [inch]: 1/2"
Material: tubular steel construction, high-quality plastic parts
Number of teeth: 48
Scope: AssemblyProduction Maintenance and repair
Calibration length: 435.2 mm
Torque range (min./max.) [nm].: 40 Nm - 200 Nm
Drive square [metric]: 12.5 mm
Target groups: Automotive Industry Construction and Commercial Vehicles Consumer Energy Mechanical Engineering Workshop Service Agriculture Oil and gas Utilities
Scale division [lbf-ft]: 10 lbf-ft
Distance housing - square centre: 21.25 mm
Tightening torque (max) [lbf-ft]: 150 lbf-ft
Torque (max.) [nm].: 200 Nm

Brand GEDORE
02302319
EAN 4002805931455
Supplier number GEDORE 2641313

Frequently asked questions about this product

Answered by specialists

What is the adjustable torque range of this torque wrench?: The adjustable torque range of the Gedore DMUK 200 is 40 to 200 Nm.
What drive size does the Gedore DMUK 200 feature?: This torque wrench features a 1/2" square drive with push-button release and ball lock.
How do you know when the set torque has been reached?: The wrench mechanism provides a clear tactile and audible click signal when the target torque is reached.
Is this torque wrench VDE certified for electrical work?: No, this torque wrench is not VDE certified or insulated for live electrical applications.
How do you adjust the torque on this model?: You adjust the torque manually using the analog scale in Nm on the handle.
