What is the torque range of this torque wrench?

The adjustable torque range runs from 40 to 200 Nm (30 to 150 lbf·ft).

What drive connector size does this tool use?

It features a 14 x 18 mm rectangular cavity for insert tools.

How does the tool indicate that the set torque is reached?

The release system triggers both a tactile and an audible signal.

Can you use this torque wrench in both directions?

Yes, it is designed for controlled bi-directional tightening with suitable inserts.

What is the calibration accuracy of the Gedore DMSE 200?

It is calibrated to a maximum permissible deviation of +/- 3%.

GEDORE DMSE 200 torque spanner dremaster se 14x18, 40-200 nm - 2641461

Name: GEDORE DMSE 200 torque spanner dremaster se 14x18, 40-200 nm - 2641461
Brand: GEDORE
SKU: 02254244
Price: 221.4 EUR
Availability: PreOrder

Supplier number: GEDORE 2641461 | EAN 4002805931554

Recommended Retail Price €374.98

221.40 tax incl.

€182.98 excl. VAT (incl. all environmental contributions)

On order: delivered from 15/10/2026

Ordered before 20:00 - delivered as of 15/10/2026
Free shipping
Delivery by DHL

✆ Talk to a specialist

Controlled tightening with dependable accuracy

Practical benefits

Clear tactile and audible signal: You instantly feel and hear when your selected torque between 40 and 200 Nm is reached during assembly.
High precision with Gedore: You achieve dependable tightening results thanks to a calibrated tolerance of maximum 3% deviation.
Versatile rectangular drive cavity: The 14x18 mm rectangular holder lets you quickly swap end fittings for controlled clockwise and counter-clockwise tightening.

In a nutshell

The right choise for

With the Gedore dmse 200 Dremaster se torque wrench, you achieve controlled bolt tightening with dependable accuracy. Covering a torque range of 40 to 200 Nm with a calibrated tolerance of maximum 3% deviation, it reliably prevents over-tightening, sheared bolts, and loose connections. The release mechanism provides a clear tactile and audible signal the moment your target torque is reached. Featuring a 14x18 mm rectangular drive cavity, it allows seamless swapping of insert tools for bi-directional tightening in mechanical engineering, maintenance, and automotive workshops.

Product information FAQ

€221.40

tax incl.

Key features according to our expert

Max. tightening torque: 400 Nm
Drive profile size: 14 x 18 mm
VDE approved: No
With safety colour code 1000V: Not applicable
ESD: No
Display: Analogue
Min. tightening torque: 40 Nm

Product description

Application Controlled screw tightening in the range 40 - 200 Nm / 30 - 150 lbf-ft
Adjustable, audible and tactile switch-off robust torque spanner with rectangular SE take-up
Design Classified according to DIN EN ISO 6789-22017 Type II Class A, incl traceable test certificate, calibrated with a maximum permissible deviation of +/- 3% and thus more accurate than the /- 4% prescribed by the standard.
For controlled clockwise and anticlockwise tightening
Double scale N-m and lbf-ft under a viewing window with magnifying glass effect
Ergonomically shaped plastic handle with calibration aid
Switchover between main scale Nm and secondary scale lbf-ft for avoiding reading errors when setting the desired torque
With micrometer scale for Nm main scale for setting intermediate scale values
Automatic switch-off using audible and tactile signal
Ergonomic torque adjustment system with instruction symbol
Secure adjustment system
Operation only with plug-in tools of uniform pitch - otherwise value shifts may occur.
Operation only with plug-in tools with uniform pitch - otherwise value shifts may occur
Depending on the tool application, work can be carried out either forwards (e.g. open-end spanner) or sideways (e.g. switchable ratchet and socket spanner)

All Features

Max. tightening torque: 400 Nm
Drive profile size: 14 x 18 mm
Vde approved: No
With safety colour code 1000v: Not applicable
Esd: No
Display: Analogue
Min. tightening torque: 40 Nm
Pitch size [metric]: 25.0 mm
Drive intake, rectangular...: 14 x 18 mm
Fixed setting: No
Drive type/drive: Rectangle recording
Tightening torque (min.) [lbf-ft]: 30 lbf-ft
Lever length drive side [mm]: 42 mm
Precision +/-: +/- 3 %
Test certificate: DIN EN ISO 6789-2:2017
Scale division [nm]: 10 Nm
Vernier nm: 1 Nm
Storage/contents: Plastic box
Tightening direction: Left and right
Overall length [mm]: 499.5 mm
Torque (min.) [nm].: 40 Nm
Take-up height [mm]: 25 mm
Calibration length: 427.2 mm
Tightening range (min/max) [lbf-ft].: 30 lbf-ft - 150 lbf-ft
Scope: MountingSeries assembly Production Maintenance and repair
Material: tubular steel construction, high-quality plastic parts
Torque range (min./max.) [nm].: 40 Nm - 200 Nm
Lever length handle side [mm]: 457.5 mm
Target groups: AutomotiveIndustry Construction and commercial vehicles Military Energy Mechanical Engineering Utilities Service Agriculture Oil and gas
Scale division [lbf-ft]: 10 lbf-ft
Turn-off mechanism: Short road clearance
Distance housing - square centre: 27.5 mm
Tightening torque (max) [lbf-ft]: 150 lbf-ft
Take-up width [mm]: 33 mm
Torque (max.) [nm].: 200 Nm

Brand GEDORE
02254244
EAN 4002805931554
Supplier number GEDORE 2641461

Frequently asked questions about this product

Answered by specialists

What is the torque range of this torque wrench?: The adjustable torque range runs from 40 to 200 Nm (30 to 150 lbf·ft).
What drive connector size does this tool use?: It features a 14 x 18 mm rectangular cavity for insert tools.
How does the tool indicate that the set torque is reached?: The release system triggers both a tactile and an audible signal.
Can you use this torque wrench in both directions?: Yes, it is designed for controlled bi-directional tightening with suitable inserts.
What is the calibration accuracy of the Gedore DMSE 200?: It is calibrated to a maximum permissible deviation of +/- 3%.
